Specifications Summary

Video Formats:
Storage: 100 Total
Built-in: VESA Standards
NTSC (607, 608, 609)
PAL (607, 608, 609)
HDTV (608, 609)
Edit Method: Quantum Data's MS-Windows
based VGM software
Test Patterns (Images)
Blank Raster, Flat White, Flat Red, Flat
Green, Flat Blue, Grid, Grids, Overscan,
Cutoff, Window, Focus, Color Bar, Gray Bar,
HV Regulation, Dots, SMPTE Bar, Ramp,
Burst, Pulse Bar
Horizontal Timing
Frequency: 1 KHz to 250 KHz
Total Pixels: 144 to 4096
Active Range: 16 to 4096 pixels
Vertical Timing
Frequency: 1 Hz to 650 Hz
Active Lines: 1 to 4096
Scan Types: Progressive, 2:1 Interlace
Sync Types
Separate Digital Horizontal and Vertical
Digital and Analog Composite
Bipolar HDTV (608, 609)
Part 68-00189 Rev I
Video Outputs
Timing Accuracy: 2%
Connectors: See diagram on page 3.
RF Output (Not all Models)
Channels: UHF channels with
frequencies per NTSC (M)
and PAL (G). Specific channel
usage/availability determined
by current firmware.
Video: Color per NTSC (M) and PAL
(G)
Audio: Mono 1 KHz Tone per NTSC
(M) and PAL (G)
Connector: Female F type
Audio Outputs (Not all Models)
Connecter: 3.5 mm Stereo phone jack
See pg. 3 for wiring info.
Signals: Left — 1 KHz Tone
Right — 2 KHz Tone
User Interface
Display: 20x4 character backlit LCD
Buttons: 9 function buttons, 8 Menu
buttons, 2 page up/down
buttons. See page 4 for more
information.
Computer Interface
Type: RS-232, 9 pin D-sub
See pg. 3 for pinout
Protocol: 9600 Baud, 8-N-1, Xon/Xoff
VESA EDID/DDC Support
Reads a monitor 's EDID data through HD-15
VGA connector and shows list of supported
standard formats. DDC test mode for cycling
through supported standard formats.
Battery Power Operation
Type: Four AA batteries installed
internally.
1500 mA-H rated
rechargeable NiMH batteries
supplied with unit.
Use Time: 8 hours typical with supplied
NiMH batteries when fully
charged. Shortened when
using backlight or RF output.
AC Power Operation
Type: External Charger / Power
Supply supplied with unit
AC Input Range: 86 to 250 VAC
@ 46 to 66 Hz
Generator Size and Weight
Size: 5.5 x 8.25 x 2 inches
140 x 210 x 51 mm
Weight: 4 lb. w/ supplied batteries
installed
