Parts list
8. Parts list
APP 3.0 - 3.5
10 36
APP 0.6-43 / APM 0.8-2.9 / APP W 5.1-10.2
Note:
The parts listed are not sold separately, only in
various kits.
Exploded view, see next page.
Pos. Qnt. Designation
1 1 Housing
2 1 Pin (Ø4x14)
31 1 Swash plate
32 1 Centre bolt
33 1 Pin (Ø6x10)
61 1 Cylinder barrel
62 1 Spring
63 1 Spring guide
64 1 Retainer ball
65 1 Retainer plate
66 7 Piston
67 1 Key (5x5x20)
91 1 Port plate
92 1 Valve plate
93 7 Back-up ring
94 7 O-ring (Ø13x2.0)
121 1 Port flange
122 1 O-ring (Ø83x2)
123 1 O-ring (Ø40x2)
124 1 Shaft seal
125 1 Mounting flange
126 1 Pin (Ø4x9)
127 4 Screw (M6x45)
128 2 Screw (M6x16)
129 2 Bleeding plug
130 2 O-ring (Ø4.5x1.5)
152 1 Valve cone
153 1 Spring
154 1 Plug/guide
155 1 O-ring (Ø11.11x1.78)
