Figure 2. VEP1405 desktop placement
Wall mount installation
The VEP1405 includes the hardware that is required for wall mount installation. Using a torque screwdriver, affix the wall mount brackets
to the VEP1405 using the four M3 screws included.
NOTE: When driving the screws into the bracket and VEP1405 unit, verify that 5 lb-in is the achieved torque setting.
NOTE: If mounting the VEP1405 to the wall using the wall mount bracket provided, removal of the rubber feet from the
bottom of the VEP1405 unit is not necessary.
The VEP1405 includes a wall mount bracket with cross-shaped cutout for the mounting screws.
Wall mount bracket with cross-shaped cutout for the mounting screws
Figure 3. VEP1405 wall mount installation - cross-shaped cutout
To mount the VEP1405 unit to the wall using the wall mount bracket provided, you must first anchor the screws into the wall surface.
Depending on the type of wall surface, use the M3 screw and anchor to ensure a secure installation. The recommended M3 screw
dimensions are as follows:
NOTE: The wall mount, installation anchor, and screw dimensions that are provided are in millimeters (mm).
Figure 4. VEP1405 wall mount, installation anchor, and screw dimensions
