VEP4600 Installation Guide
October 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEP4600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dell EMC VEP4600

Summary of Contents for Dell EMC VEP4600

  • Page 1 VEP4600 Installation Guide October 2018...
  • Page 2 Notes, cautions, and warnings NOTE: A NOTE indicates important information that helps you make better use of your product. CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

  • Page 3: Table Of Contents

    Contents 1 About this guide............................. 5 Regulatory................................... 5 Related documents................................5 Information symbols................................6 2 VEP4600 platform............................7 Introduction..................................7 Features....................................8 Physical dimensions................................8 LED display..................................8 LED behavior................................9 Pre-requisites..................................11 VEP4600 configurations..............................11 Luggage tag..................................11 3 Site preparations............................13 Site selection..................................13 Cabinet placement................................13...
  • Page 4 Korean certification of compliance.......................... 32 Safety standards and compliance agency certifications..................... 33 Electromagnetic compatibility..........................33 Product recycling and disposal............................34 Waste electrical and electronic equipment (WEEE) directive for recovery, recycle and reuse of IT and telecommunications products..........................34 9 Dell EMC support............................35 Contents...

  • Page 5: About This Guide

    When no cable is connected, visible and invisible laser radiation may emit from the aperture of the optical transceiver ports. Avoid exposure to laser radiation. Do not stare into open apertures. Regulatory Marketing model VEP4600 is represented by the regulatory model E25W and the regulatory type E25W001. Topics: •...

  • Page 6: Information Symbols

    Information symbols This book uses the following information symbols: NOTE: The Note icon signals important operational information. CAUTION: The Caution icon signals information about situations that could result in equipment damage or loss of data. WARNING: The Warning icon signals information about hardware handling that could result in injury. WARNING: The ESD Warning icon requires that you take electrostatic precautions when handling the device.

  • Page 7: Vep4600 Platform

    AC power supply units (PSUs) and four or five AC normal hot-swappable fan units, depending on the configuration. There are two fixed VEP4600 Expansion Cards slots on the I/O side which permits networking expansion with the additional network interface controller (NIC) ports.

  • Page 8: Features

    17.1 x 15 x 1.72 inches (W x D x H) • PSU/fan tray handle: 1.57 inches (40 mm) LED display The VEP4600 platform includes LED displays on the I/O side of the platform. Some LED behaviors may change after you install your software. VEP4600 platform...

  • Page 9: Led Behavior

    10/100/1000 BaseT RJ-45 networking link (left) and activity (right) LEDs 10/100/1000 BaseT RJ-45 networking link (left) and activity (right) LEDs for the processor (left) and for the BMC (right) Table 1. VEP4600 LED behavior Description System Status/Health LED • Off - system off or in standby •...
  • Page 10 Table 3. SFP+ port LEDs Description Link/Activity LED • Off—No link • Solid green—Link operating at maximum speed, 10G • Solid yellow—Link operating at a lower speed, 1G • Flashing green—port activity for 10G • Flashing yellow—port activity for 1G VEP4600 platform...

  • Page 11: Pre-Requisites

    – Four-core systems use four fans and one PSU. Luggage tag The VEP4600 has a pull-out tag, known as a luggage tag, on the I/O-side of the platform. The front of the luggage tag includes platform ID information. VEP4600 platform...
  • Page 12 Figure 5. VEP4600 luggage tag SVC tag MAC address PPID Express service code VEP4600 platform...

  • Page 13: Site Preparations

    Site preparations VEP4600 is universal customer premise equipment (uCPE). To connect the service provider edge or enterprise branch to the cloud, use VEP4600 to host multiple virtual network functions (VNFs), such as SD-WAN, routing, firewall, and deep-packet inspection. For more information about platform specifications, see Specifications.

  • Page 14: Rack Mounting

    For proper ventilation, position the platform in an equipment rack or cabinet with a minimum of 5 inches (12.7 cm) of clearance around the exhaust vents. When you install two VEP4600 platforms near each other, to permit proper airflow, position the two platforms at least 5 inches (12.7 cm) apart.

  • Page 15: Storing Components

    Storing components If you do not install your VEP4600 and components immediately, properly store the platform and all optional components using these guidelines: • Storage location temperature must remain constant. The storage range is from -40°C to 70°C (-40°F to 158°F).

  • Page 16: Vep4600 Installation

    Ground lug Dell EMC recommends you ground your switch; however, grounding is optional and the ground lug assembly kit is not included with the switch. The ground lug must be a UL-recognized, crimp-type lug. To order a UL-certified ground lug with bracket, contact your Dell EMC sales representative.

  • Page 17: Rack Or Cabinet Hardware Installation

    NOTE: For AC-powered platforms, although the third conductor of the AC power cord provides a ground path, Dell EMC recommends grounding your platform with a dedicated ground wire. To attach a ground lug assembly to the switch, use the included two M3 ground lug bracket screws. The switch ships with the M3 ground lug bracket screws attached.

  • Page 18: Rack Mount Safety Considerations

    Do not mount the equipment with the back panel facing downward. Two-post installation To easily configure your rack for installation of the VEP4600, use the two-post rack mounting system provided. To complete this installation, supply four rack-mounting screws. To begin installation, separate each rail assembly by sliding the inside rail out of the outside rail.

  • Page 19: Four-Post Installation

    Separate each rail assembly by sliding the inside rail out of the outside rail. Attach the inner platform rails to the VEP4600. Line up the half-holes on the rail with the mounting heads on the platform and attach the rail to the platform. Slide the rail back until it locks into place.
  • Page 20 Figure 12. Platform four-post rear installed About three inches before you fully insert your platform, the rail locking feature engages to keep the platform from inadvertently sliding out and falling. To remove the platform, unscrew the rack-mounting screws and slide the platform forward. VEP4600 installation...

  • Page 21: Optics Installation

    Do not jerk or tug repeatedly on the tab. Platform power-up Supply power to the VEP4600 after it is mounted in a rack or cabinet. Dell EMC recommends reinspecting your platform before powering it up. Verify the following: •...

  • Page 22: Power Supplies

    Power supplies The VEP4600 ships with one or two AC power supplies, depending on the configuration. Airflow is from the I/O panel to the PSU—the red indicator is the normal airflow direction. Two PSUs are required for full redundancy, but the platform can operate with a single PSU.

  • Page 23: Ac Power Supply Installation

    Plug in the appropriate AC 3-prongs cord from the platform PSU to the external power source. Repeat steps 1 through 4 if you have a redundant PSU using the second PSU slot. NOTE: The VEP4600 powers up when you connect the cables between the power supply and the power source. AC power supply replacement CAUTION: Disconnect the power cord before removing the power supplies.
  • Page 24 NOTE: If you use a single PSU, install a blank plate in the other PSU slot. If you are only using one power supply, install the power supply in the first slot, PSU1. Install a blank plate in the second slot, PSU2. Disconnect the power cable from the PSU.

  • Page 25: Fans

    Fans The VEP4600 comes from the factory with one or two PSUs and four or five AC normal fan modules installed in the platform, depending on the configuration. The fan modules and the power supplies, which have integrated fans, are hot-swappable.

  • Page 26: Fan Module Installation

    Fan module installation The fan modules in the VEP4600 are field replaceable. Module slot 1 is on the left side of the platform; module slot 5 is on the right side of the platform. Take the fan module out of the shipping box.

  • Page 27: Management Ports

    Management ports Besides the 10/100/1000Base-T RJ-45 ports, the VEP4600 provides several ports for management and storage. NOTE: The output examples in this section are for reference only. Your output may vary. Topics: • RS-232 console port access • MicroUSB-B console port access RS-232 console port access The RS-232 console port is on the I/O-side of the VEP4600.

  • Page 28: Microusb-B Console Port Access

    Power on the platform. Install the necessary USB device drivers. To download Dell EMC drivers, see https://www.dell.com/support. If your computer requires non-Dell EMC drivers, contact Dell EMC Technical Support for assistance. Open your terminal software emulation program to access the platform.

  • Page 29: Specifications

    Specifications This section lists the VEP4600 specifications. CAUTION: Operate the product at an ambient temperature not higher than 113°F (45°C). CAUTION: Lithium Battery Caution: There is a danger of explosion if the battery is incorrectly replaced. Replace only with same or equivalent type of battery.

  • Page 30: Ieee Standards

    25G Etherenet Consortium 25 Agency compliance The VEP4600 is designed to comply with the following safety and agency requirements: USA Federal Communications Commission statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules.

  • Page 31: European Union Emc Directive Conformance Statement

    Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Dell EMC is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications in the equipment.

  • Page 32: Japan Vcci Compliance For Class A Equipment

    (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions. WARNING: Use the AC power cords with Dell EMC equipment only. Do not use Dell EMC AC power cords with any unauthorized hardware. Figure 20. Japan: warning label Korean certification of compliance Figure 21.

  • Page 33: Safety Standards And Compliance Agency Certifications

    Figure 22. Korean package label Safety standards and compliance agency certifications • CUS UL 60950-1, 2nd Edition • CSA 60950-1-03, 2nd Edition • EN 60950-1, 2nd Edition • EN 60825-1, 1st Edition • EN 60825-1 Safety of Laser Products—Part 1: Equipment Classification Requirements and User’s Guide •...

  • Page 34: Product Recycling And Disposal

    You must recycle or discard this platform according to applicable local and national regulations. Dell EMC encourages owners of information technology (IT) equipment to responsibly recycle their equipment when it is no longer needed. Dell EMC offers a variety of product return programs and services in several countries to assist equipment owners in recycling their IT products.

  • Page 35: Dell Emc Support

    The Dell EMC support site provides integrated, secure access to these services. To access the Dell EMC support site, go to www.dell.com/support/. To display information in your language, scroll down to the bottom of the web page and select your country from the drop-down menu.
