Instrument and control functions

Shift pedal

1
4
ZAUV0311
1. Shift pedal
The shift pedal is located on the left
side of the motorcycle. This motorcy-
cle is equipped with a constant-mesh 4
speed transmission.
TIP
Use your toes to shift up and your heel
to shift down.
EAU37462

Front brake lever

1
ZAUV0673
1. Front brake lever
The front brake lever is located on the
right side of the handlebar. To apply
the front brake, pull this lever toward
the throttle grip.
EAU12902

Brake pedal

ZAUV0313
1. Brake pedal
The brake pedal is located on the right
side of the motorcycle. To apply the
rear brake, press down on the brake
pedal.
4-5
