Fuel gauge

1 2
ZAUV0308
1. Red zone
2. Fuel gauge
The fuel gauge indicates the amount of
fuel in the fuel tank. The needle moves
towards "E" (Empty) as the fuel level
decreases. When the needle reaches
the red zone, refuel as soon as possi-
ble.
TIP
Turning the key to "OFF" cancels the
fuel gauge reading.
EAUW0302

Handlebar switches

Left
1 2 3
OK
ZAUV0612
1. Horn switch "
2. Turn signal switch "
3. Dimmer switch "
Right
ZAUV0672
1. Start switch " "
Instrument and control functions
EAU1234K
Dimmer switch "
Set this switch to "
beam and to "
Turn signal switch "
To signal a right-hand turn, push this
switch to "
turn, push this switch to "
released, the switch returns to the cen-
ter position. To cancel the turn signal
lights, push the switch in after it has re-
turned to the center position.
"
/ "
/ "
Horn switch "
Press this switch to sound the horn.
Start switch "
Push this switch to crank the engine
with the starter. See page 6-1 for start-
ing instructions prior to starting the en-
1
gine.
4-4
EAU12401
/ "
" for the high
" for the low beam.
EAU12461
/ "
". To signal a left-hand
". When
EAU12501
"
EAU12713
"
4
