Instrument and control functions

Main switch/steering lock

4
ZAUV0300
The main switch/steering lock controls
the ignition and lighting systems, and is
used to lock the steering, and is used
to open the seat also. The various main
switch positions are described below.
TIP
The main switch is equipped with a
keyhole cover. (See page 4-2 for key-
hole cover opening and closing proce-
dures.)
ON
All electrical systems are supplied with
power, and the engine can be started.
The key cannot be removed.
EAUU0351
OFF
All electrical systems are off. The key
can be removed.
WARNING
Never turn the key to "OFF" or
"LOCK" while the vehicle is moving.
Otherwise the electrical systems will
be switched off, which may result in
loss of control or an accident.
LOCK
The steering is locked, and all electrical
systems are off. The key can be re-
moved.
To lock the steering
EAU10631 LOCK
ZAUV0301
EAU10662 1. Turn the handlebars all the way to
2. Push the key in from the "OFF"
EWA10062
3. Remove the key.
TIP
If the steering will not lock, try turning
the handlebars back to the right slight-
ly.
To unlock the steering
EAUU1043
OFF
ZAUV0302
Push the key in, and then turn it to
"OFF" while still pushing it.
4-1
the left.
position, and then turn it to
"LOCK" while still pushing it.
OFF
LOCK
