Connection diagram – 3P+N (3*400V)
Brown – L1
Black – L2
Grey – L3
Blue – Neutral
REMARK: The above wiring and colour scheme is indicative. National regulations
must be respected. Wiring for Europe must be at least 1mm
protected by a 6A circuit breaker.
Smappee Infinity – Installation manual – English
