The arrow indicated on the
CT (K > L) must point in the
direction of the current flow.
Mount the supplied bus
termination plug in the free
port of the last CT Hub.
You can use a custom RJ10 cable instead of the standard Smappee Bus cable. The
RJ10 must be a twisted pair cable. Pins 1 & 4 and Pins 2 & 3 must be twisted pairs.
See the Smappee Bus cable specification in section 11.
