Advantech PCM-4390 Startup Manual

PCM-4390 Onboard Intel
SBC with LCD/LVDS/GIGA LAN/8 GPIO/ 8 USB2.0
Startup Manual
Packing List
Before installation, please make sure that you have
received the following:
• 1 PCM-4390 SBC
• 1 Startup Manual
• 1 Utility CD
• 1 Cable 20P/10P 10CM EPIC
ATX Power
• Flat cable 44P IDC 44P/44P/
40P Keyed 50cm
• Keyboard/Mouse Connector
• FLAT Cable 50P 20CM 3Com
& LPT 1.27mm to D-sub
• Cable Serial ATA 7P/7P100cm
• Wire RS-422/485 W/D-SUB
COM 4P 15cm
If anything is missing or damaged, contact your distributor
or sales representative immediately.
Note 1: For detailed contents or the PCM-4390, please
refer to the enclosed CD Disc or disc(in PDF for-
mat).
Note 2: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
http://www.adobe.com/products/acrobat/
readerstep2.html(Acrobat is a trademark of
Adobe).
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/eservice/
This manual is for the PCM-4390 Series Rev. A1.
Part No. 2006439000
1 PCM-4390 Startup Manual
®
Specifications
Standard SBC Functions
• CPU: Embedded Intel Core Duo Processor, up to 1.66
• System Chipset: Intel 945GM GMCH/ICH7M Chipset
• BIOS: AWARD
• System memory: 200-pin SODIMM socket Rate II
p/n: 1700002055
p/n: 1701440504
• Power Management: APM1.2, ACPI support
• SSD: USB-DOM
p/n: 1700060202
• Watchdog: Timer Single chip Watchdog 255-level inter-
p/n: 1700002034
• Expansion: Interface PCI-104
p/n: 1700071000
• Battery: 2-pin wafer box for external Battery on board I/
p/n: 1703040157
• I/O Interface: 1 x EIDE (UDMA 33),
• USB: 8 x USB 2.0 compliant Ports
• Audio: ICH7M AC97 3D surround stereo sound Sup-
• IrDA: N/A
• GPIO: 8-bit general purpose input/output
Ethernet
• Chipset: BroadCom BCM5721
• Speed: 10/100/1000 Mbps
• Interface: 2 x RJ45
• Standard: IEEE 802.3u 100Base-T
Display
• Chipset: Intel 945GM chip integrated.
• Memory Size: Optimized Shared Memory Architecture,
• Resolution
• LCD Interface: 2 Dual Channel (LVDS1 x 36-bit, LVDS2
• LVDS: Hirose connector supports up to 2 channel(2 x
• Dual Independent: CRT + 36-bit LVDS, LVDS +
1st Edition
May 2007.
Core Duo 4" EPIC
GHz
®
4 Mbit Flash BIOS
(DDR2) 128 MB to 1 GB, accept 128/256/512/1 G
(DDR2) 400/533/667 DRAM
val timer, setup by software
O
1 x K/B (optional), 1 x KB/mouse, 3 x RS232,
1 x RS232/422/485, 1 x LPT
(2 ports on board connector, 6 ports pinhead)
ports Line -in, Line-out, Microphone-in (with PCM-410
option)
(Extreme Graphics 2)
supports up to 64 MB frame buffer using system mem-
ory
CRT Display mode: pixel resolution up to 1600 x 1200 at
85-Hz and 2048 x 1536 at 75-Hz LCD
Display mode: Dual channel LVDS panel supports up to
UXGA panel resolution with frequency range from 25
MHz to 112 MHz
x 48-bit(Optional) ) LVDS
18-bit) LVDS LCD Panel
LVDS(Dual LVDS optional)
