Advantech PCM-4153-A2 Startup Manual

PCM-4153-A2 PC/104+ SBC w/AMD LX800, VGA, LCD,
Dual LAN, USB 2.0, On-board Flash and Memory
Startup Manual

Packing List

Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 x PCM-4153 SBC
• 1 x AT Power cable
• 1 x Audio cable
• 1 x Four COM cable
• 1 X RS-422/485 COM cable
• 1 x Keyboard/Mouse cable
• 1 x Y cable (for KB/MS extention)
• 2 x Ethernet RJ-45 Conn.
conversion cable
• 1 x LPT port cable
• 1 x IDE cable
• 1 x VGA cable
• 2 x USB cable
(bracket type with two USB ports)
• 1 x Startup manual
• 1 x CD-ROM (Manual, Driver, Utility)
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1:
For detailed contents of PCM-4153-A2, please
refer to information on the enclosed CD-ROM (in
PDF format).
Note 2:
Acrobat Reader is required to view any PDF
file.Acrobat Reader can be downloaded at:
www.adobe.com/Products/acrobat/readstep2.
html (Acrobat is a trademark of Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/suppot/
This manual is for the PCM-4153 Series Rev. A2
Part No. 2006415301
Print in China
(p/n:1700003491)
(p/n:1700000918)
(p/n:1701400181)
(p/n:1703040157)
(p/n:1703060053)
(p/n:1700060202)
(p/n:1700005158)
(p/n:1700260250)
(p/n:1701440350)
(p/n:1700000898)
(p/n:1703100121)
2nd Edition,
April 2009
Specifications

Standard SBC Functions

• CPU: AMD Geode® LX800 processor, up to 500 MHz
• System Memory: On-board memory DDR333 SDRAM
512 MB
• 2nd Cache Memory: 128 KB on the processor
• System Chipset: AMD Geode LX800
• BIOS: Award 4 Mbit Flash BIOS
• Watchdog Timer: 255 levels timer interval
• Expansion Interface: PC/104+
• Battery: Lithium 3 V / 196 mAH
• Power management: ACPI supported
• Enhanced IDE interface: One channel supports one
EIDE device (another is used for on board IDE Flash).
BIOS auto-detect, PIO Mode 3 or Mode 4, supports
UDMA 33 mode
• Flash: onboard 1 GB Flash (IDE interface)
• Serial ports: Four serial RS-232 ports in one pinheader
40 pin connector (CN30: COM1/2/3/4). RS-422 and RS-
485 in one pinheader and can be configured via CN39
connector
• Parallel port: One parallel port, supports SPP/EPP/ECP
mode
• Keyboard/mouse connector: Supports one standard
PC/AT keyboard and a PS/2 mouse
• Audio: Supports AC97 Audio stereo sound
• USB: Four USB 2.0 compliant universal serial bus ports
• GPIO: 8 bit general purpose Input/Output
VGA/LVDS Interface
• Memory Size: Optimized Shared Memory Architecture,
supports up to 64MB frame buffer using system memory
• Resolution:
CRT resolution: up to 1600 x 1200 x 16 bpp at 100 Hz
and up to 1024 x 768 x 32 bpp at 60 Hz for TFT LCD
LCD interface: Supports up to 24-bit TFT LCD (TTLsig-
nal)
• Dual Simultaneous Display: CRT+LCD
Ethernet interface
• Chipset supports: 2 x 10/100Mbps - Intel 82551ER
• Ethernet interface: IEEE 802.3u (100 BASE-T) protocol
compatible
• Connector: Two internal box headers
Audio Function
• Audio controller: Realtek ACL203 chipset, supports
AC97 3D Audio stereo sound
• Audio Interface: Microphone in, Line in, Line out
PCM-4153-A2 Startup Manual 1
