Advantech PCM-4380 Startup Manual

PCM-4380 Pentium® M 4" SBC with MIO/VGA/
LVDS Ethernet/USB2.0
Startup Manual

Packing List

Before you begin installing your card, please make sure
that the following materials have been shipped:
• 1 PCM-4380 SBC
• 1 Startup manual
• 1 Utility CD
• Cable 20P/10P 10 cm EPIC
ATX Power (CN1)
• Cable 2*4P/10P EPIC AT
POWER 15 cm (CN1)
• Flat Cable 44P IDC 44P/44P/
40P Keyed 50 cm (CN27)
• USB CABLE 20 Pin to 2 Port
L=30 cm (CN31)
• Keyboard/Mouse Connector
(CN19)
• Flat cable 44P 20 cm 3COM
& LPT 1.27 mm to D-sub
(CN30)
• CABLE USB*2/10-2.0 mm 29
cm
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Note 1: For detailed contents of the PCM-4380, please
refer to the enclosed CD Disc or disk (in PDF for-
mat).
Note 2: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
http://www.adobe.com/products/acrobat/
readstep2.html (Acrobat is a trademark of Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the PCM-4380 Series Rev. A2.
Part No. 2006438001

Standard SBC Functions

• CPU: Embedded Intel Pentium M/Celeron M
p/n: 1700002055
• System Chipset: Intel 855GME GMCH/ICH4 Chipset
p/n: 1700003931
• BIOS: Award 512 Kbit Flash BIOS
• System Memory: 200 pin SODIMM socket, support
p/n: 1701440504
p/n: 1700004891
• Power Management: APM1.2, ACPI support
• SDD: Supports CompactFlash Card Type I/II (shared
p/n: 1700060202
• WatchDog Timer: Single chip watchdog 255-level timer
p/n: 1700002034
• Expansion Interface: Supports 8/16 bit ISA bus for
p/n:1700001267
• Battery: 2 pin wafer box for external Battery on board
(PCM-4380U series
only)
• USB: 4 x USB 2.0 compliant ports
• GPIO: 8-bit general purpose input/output

Solid State Disk

• Supports one 50-pin socket for CFC type I/II

VGA/LVDS Interface

• Chipset: Intel 855GME chip integrated (Extreme Graph-
• Memory Size: Optimized Shared Memory Architecture,
• Resolution:
• LCD Interface: 2 Channel (2 x 18/36-bit) LVDS
• LVDS: Hirose connector support up to 2 channel (2 x 18-
• Dual Independent Display: CRT+ 36-bit LVDS

Ethernet interface

• Chipset supports:
• Ethernet interface: 2 x RJ45
• Standard: IEEE 802.3u 100Base-T
2nd Edition
Oct. 2007

Specifications

on board Pentium M 1.4 GHz (2M L2 cache)
PCM-4380F-S4A2E
on board Celeron M 1.0 GHz (1M L2 cache)
PCM-4380F-S0A2E
on board Celeron M 600 MHz (512K L2 cache)
PCM-4380F-M0A2E
ECC Double Data Rate (DDR) 128 MB to 1 GB, accept
128M/256M/512M/1G, DDR 200/266/333 DRAM
2nd IDE Channel) USB memory, uDOC (option)
interval, setup by software
standard PC/104 device (ITE 8888g), PC/104-Plus
Enhance IDE Interface 1 x EIDE (UDMA 33), 1 x FDD,
UDMA 100 with PCM-063 riser card, 1 x Keyboard/
Mouse, 3 x RS232, 1 x RS-232/422/485, 1 x LPT
ics 2)
support up to 64MB frame buffer using system memory
CRT Display Mode: pixel resolution up to 1600 x 1200
@85 Hz and 2048 x 1536 @75 Hz
LCD Display Mode: Dual channel LVDS panel sup-
ports up to UXGA panel resolution with frequency
range from 25 MHz to 112MHz with frequency range
from 25 MHz to 112 MHz
bit) LVDS LCD Panel
10/100 Mbps - Intel 82551ER
10/100/1000 Mbps - Intel 82541PI (Optional)
