Advantech PCM-3910 Startup Manual

PCM-3910
Module
Startup Manual

Packing list

Before you begin installing your card, please make sure
that the following materials have been shipped:
• 1 PCM-3910
• 1 Startup manual
If any of these items are missing or damaged, contact
your distributor or sales representative immediately.
Note 1: Acrobat Reader is required to view any PDF
file. Acrobat Reader can be downloaded at:
www.adobe.com/Prodindex/acrobat/read-
step.html(Acrobat is a trademark of Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/eservice/
This manual is for the PCM-3910 series Rev. A1.
Part No. 2006391000
1 PCM-3910 Startup Manual
DC to DC power supply PC/104+
1st Edition
Mar. 2005

Specifications

5V output 10A
12Voutput 2A
-5Voutput 0.4A
-12Voutput 0.4A
10V~24V input 6.5A
Mechanical and Environmental
• Dimensions (L x W): 3.55" x 3.75" x 0.55"
• Weight: 30g
• Operating Temperature: -40 ~ 85°C(-40~185°F)
• Storage temperature: -40 ~ 85°C(-40~185°F)
• Operating Humidity: 0%~90% ralative humity,non-con-
densing
• Power Supply Voltage: 5V
• Power Consumption: 5V, ±5%

Features

50W output
10V to 24V DC input range
Reverse input protection
5V,12V,-5V,-12V outputs
P/N:2006391000
