Ashley Dolls House Bookcase
Assembly Instructions -
Dimensions
Width - 69cm
Depth - 30cm
Height - 89.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
719/1785
issue 4 3/12/10
Advertisement
Related Manuals for Argos Ashley Dolls House Bookcase
Summary of Contents for Argos Ashley Dolls House Bookcase
- Page 1 Ashley Dolls House Bookcase Assembly Instructions - 719/1785 Please keep for future reference Dimensions Width - 69cm Depth - 30cm Height - 89.5cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800...
- Page 2 “IMPORTANT: RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE”. Argos Ltd. MK9 2NW. Regularly check all fastenings This product is suitable for to ensure that they are properly children in the age of 6 or above. The maximum weight of the tightened.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline:08456 400800 Please check you have all the panels listed below Back A x 2 (59.6 x 24.6cm) Left side (68.3 x 26.8cm) Right side (68.3 x 26.8cm) Back B (59.6 x 35.5cm) Upper shelf...
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Locking pin x 5 Locking nut 13mm x 5 Dowel x 20 Wall strap x 1 45mm Screw x 13...
- Page 5 Assembly Instructions Step 1 Step 1 Fitting the dowels Insert Dowels into Middle ,Upper shelf Lower shelf , Left side and Right side Screw in Locking pins into Upper shelf Use Locking nut fix Middle onto Upper shelf...
- Page 6 Assembly Instructions Step 2 Fitting shelves Use Screws to fix Back A and Lower shelf onto the unit. Use Screws to fix Left side and Right side onto the unit. Use Caps to cover the holes on the unit. Insert Back A into the unit.
- Page 7 Assembly Instructions Step 3 Fitting the top Screw in Locking pins into Top Insert Back B into the unit. Use Locking nuts fix Top onto the unit.
- Page 8 Assembly Instructions Step 4 Fixing to wall Note: It would be useful to ask someone to help you at this stage. It is strongly recommended that the unit is attached to the wall using Wall straps Important: When drilling into walls always check that there are no hidden wires or pipes etc.
-
Page 9: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
