Verbreiterung für Gepäckbrücken
Enlargement for rear racks
KTM 1190 Adventure/R
ab Baujahr 2013 / from date of manufacture 2013
8007519 00 01
Artikel Nr.: / Item-no.:
KTM 1290 Super Adventure / R / S / T
ab Baujahr 2015 / from date of manufacture 2015
8007533 00 01
Artikel Nr.: / Item-no.:
INHALT
CONTENTS
1
700008203 Verbreiterung
4
Linsenschraube M8 x 40
4
U-Scheibe ø8,4
4
Aludistanz ( schwarz ) Ø 18 x Ø 9 x 25mm
1
Logo Hepco & Becker ø30mm
WICHTIG
IMPORTANT
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,
wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle zugänglichen
Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das entsprechende
Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist. Anzugsmomente
beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
Zur Montage ist eine zweite Person hilfreich.
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
To mount this tank guard, a second person is helpful.
schwarz/black
schwarz/black
1
700008203 enlargement
4
filister head screw M8 x 40
4
washer ø8,4
4
alu spacer (black) Ø 18 x Ø 9 x 25mm
1
emblem Hepco & Becker
1
