Motorschutzbügel/ Engine guard
KAWASAKI Vulcan S
ab Baujahr 2015 / from date of manufacture 2015
Artikel Nr.: / Item-no.:
2524
501
00 01
schwarz/black
INHALT
CONTENTS
1
700008922 Motorschutzbügel links schwarz
1
700008923 Motorschutzbügel rechts schwarz
1
700008924 Verbindungsbügel
1
700008925 Schraubensatz:
2x Sechskantschraube M8 x 60 mm
2x Sechskantschraube M8 x 30 mm
4x Sechskantschraube M8 x 16 mm
10x U-Scheiben Ø8,4
2x selbstsichernde Mutter M8
WICHTIG
IMPORTANT
Beachten Sie die in Ihrem Land geltenden Zulassungsbestimmungen.
Für den Bereich der BRD gilt: Ein Eintrag in die Fahrzeugpapiere ist nicht erforderlich.
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind, wie man
eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle zugänglichen Schrauben
zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das entsprechende Anzugsmoment
festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist. Anzugsmomente beachten! Nach
der Montage alle Verschraubungen auf festen Sitz kontrollieren!
Zur Montage ist eine zweite Person hilfreich.
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action, you
should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws should
be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe the tightening
torques of the manufacturer! Control all screw connections after the assembling for tightness!
To mount this guard, a second person is helpful.
1
700008922 Engine guard left black
1
700008923 Engine guard right black
1
700008924 Bracing bow
1
700008925 Srew kit:
2x hexagon bolt M8 x 60 mm
2x hexagon bolt M8 x 30 mm
4x hexagon bolt M8 x 16 mm
10x washer Ø8,4
2x self-lock nut M8
1
