hepco & becker 650206 00 01 Assembling Instructions

Side carrier
KAWASAKI KLR 650
US-Model (2008-)
Item-No.: 650206 00 01 black
Assembling instructions
The kit includes the following parts:
Quant item no. description
1 700007643 carrier left
1 700007644 carrier right
1 700007645 mounting adapter front left
1 700007646 mounting adapter front right
1 700007647 mounting adapter top left
1 700007648 mounting adapter top right
1 700007649 bracing bow
1 700011361 screw kit:
4 allen screw M 6 x 20
4 filister head screw M 6 x 30
2 allen screw M 8 x 55
4 allen screw M 8 x 30
2
4
7
Quant item no. description
4 lock it screw
4 lock washer
12 washer ø6,4
6 washer ø8,4
8 s e l f - n o c k
2 spacer ø13 x ø9 x 12 mm
Tip:
Fit all parts and screw on not too strong.
After mounting all parts, the screws should be tightened
to the torque specified.
This guarantees, that the kit is mounted without tension.
1
5
n u t M 6
6
3
4
1
