LEGRAND KENALL MILLENIUM METREX METSW Series Installation Instructions

MILLENIUM METREX
METSW SERIES
When using electrical equipment, basic safety precautions should always be followed, including the following:
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY A PERSON FAMILIAR WITH
THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED. DISCONNECT POWER TO ALL CIRCUITS
BEFORE WIRING FIXTURE. INSTALL IN ACCORDANCE WITH ALL NATIONAL, STATE, AND LOCAL CODES. DO NOT CONNECT TO
AN UNGROUNDED SUPPLY. READ ALL FIXTURE MARKINGS AND LABELS TO ENSURE CORRECT INSTALLATION OF FIXTURE.
SUPPLEMENTAL INSTRUCTIONS MAY BE LOCATED ON THE FIXTURE, IN ADDITION TO THIS INSTRUCTION SHEET, REGARDING
INSTALLATION INSTRUCTIONS
• All Mounting Types Remove ELECTRICAL
CHASSIS by pushing down on tabs and
pulling out.
• MMEX Wall Mounting:
Locate and remove (4) 5/16" dia.
knockouts and (1) 7/8" dia. knockout on
back surface of HOUSING. Place HOUSING
over an installed electrical junction box
Locate and drill (4) pilot holes in mounting
surface using HOUSING as template. For wet
location installation, remove tear-off sections
of self-adhesive pad GASKET and attach
to HOUSING. Using 1/4-20 fasteners
and anchors suitable for the mounting
surface (not supplied), attach HOUSING
to structure.
www.kenall.com | P: 800-4-Kenall | F: 262-891-9701 | 10200 55th Street Kenosha, Wisconsin 53144, USA
This product complies with the Buy American Act: manufactured in the United State swith more than 50% of the component cost of US origin It may be covered by patents
found at www.kenall.com/patents. Content of speci cation sheets is subject to change; please consult www.kenall.com for current product details. ©2019 Kenall Mfg. Co.
™
•
•
•
•
•
ORIENTATION, OR MOUNTING RESTRICTIONS.
SAVE THESE INSTRUCTIONS
INSTALLATION INSTRUCTIONS

IMPORTANT SAFEGUARDS

READ AND FOLLOW ALL SAFETY INSTRUCTIONS
DO NOT USE OUTDOORS.
DO NOT MOUNT NEAR GAS OR ELECTRIC HEATERS.
EQUIPMENT SHOULD BE MOUNTED IN LOCATIONS AND AT HEIGHTS WHERE
IT WILL NOT BE SUBJECTED TO TAMPERING BY UNAUTHORIZED PERSONNEL.
THE USE OF ACCESSORY EQUIPMENT NOT RECOMMENDED BY THE
MANUFACTURER MAY CAUSE AN UNSAFE CONDITION.
DO NOT USE THIS EQUIPMENT FOR OTHER THAN ITS INTENDED USE.
• Canopy Mounting: Locate
and remove (2) 5/16" dia. knockouts
and (1) 7/8" dia. knockout either from
end (for side canopy mounting) or top
(for top canopy mounting) of fixture.
Place MOUNTING PLATE over an installed
electrical junction box (slotted holes
provided for temporary j-box attachment
prior to permanent mounting). Locate and
drill (4) pilot holes in mounting surface using
MOUNTING PLATE as template. For wet location
installation, attach self-adhesive pad GASKET to
MOUNTING PLATE. Using 1/4-20 fasteners and
anchors appropriate for the mounting surface
(not supplied), attach MOUNTING PLATE to
structure. Connect supply ground to GROUND
WIRE provided. For wet
location installation, attach self-adhesive pad
GASKET to CANOPY COVER. Using HARDWARE
provided, attach CANOPY COVER and
HOUSING to CANOPY MOUNTING PLATE.
1
F-3842
