- Page 1 EXPRESS KIT - On top of any flooring surface INSTALLATION GUIDE Instructions to install Express Kit on top of any flooring surface WWW.CONNECTRAC.COM 02182021 PAGE 1...
- Page 2 Secured with set screws Overview Video available at: Q U E S T I O N S ? C A L L U S AT 8 7 7. 4 8 0 . 5 6 3 7 https://vimeo.com/412915841 WWW.CONNECTRAC.COM 02182021 PAGE 2...
- Page 3 (Allow 10” for device). anywhere in the wireway). Screw the bottom track to the floor - we recommend staggering one screw every 18”-24” . You must use the grooves on either side of the bottom track to stagger screws WWW.CONNECTRAC.COM 02182021 PAGE 3...
- Page 4 DATA TO EITHER SIDE POWER DOWN CENTER WIRE MANAGEMENT CLIPS To protect cables and to make it easier to install the top cap, snap the clip into the grooves on both sides of the bottom track. WWW.CONNECTRAC.COM 02182021 PAGE 4...
- Page 5 Set aside the frontplate until after the against the wall base, making sure to align top cap is installed, then snap the front- the legs in the aluminum bottom track. plate onto the backplate. Use screws for additional support. Alternate wall application: WWW.CONNECTRAC.COM 02182021 PAGE 5...
- Page 6 TO THIS NOTCH 2) For the second cut, measure from the end of the wireway to the end of the device (minimum length 2”). Then snap those top cap pieces into your wireway. MEASURE END TO END WWW.CONNECTRAC.COM 02182021 PAGE 6...
- Page 7 EXPRESS KIT - On top of any flooring surface INSTALLING RECEPTACLE DEVICE COVER The last step is to terminate any data cabling, and attach the cover to the electrical device. Snap in Keystones WWW.CONNECTRAC.COM 02182021 PAGE 7...
- Page 8 Insert as shown, then tighten set screws. STAGGER THE BOT TOM TRACK AND THE TOP CAP Offset the bottom track joints from the top cap joints. This helps strengthen the assembly. Stagger joints at least six inches WWW.CONNECTRAC.COM 02182021 PAGE 8...
