- Page 1 9190A Ultra-Cool Drywell Getting Started PN 4106657 January 2013 © 2013 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
- Page 2 LIMITED WARRANTY AND LIMITATION OF LIABILITY Each Fluke product is warranted to be free from defects in material and workmanship under normal use and service. The warranty period is one year and begins on the date of shipment. Parts, product repairs, and services are warranted for 90 days.
-
Page 3: Table Of Contents
Table of Contents Title Page Introduction ......................1 Contact Fluke Calibration .................. 1 Safety Information ..................... 2 Calibrator Features ..................... 4 Display and Control Panel ................5 -P Option Panel (Input Panel) ................ 6 Power and Remote Interface Panel ..............7 Main Screen .................... - Page 4 9190A Getting Started...
- Page 5 List of Tables Table Title Page Symbols ........................3 Front Panel ......................4 Display and Control Panel..................5 -P Option Panel (Input Panel) ................6 Power and Remote Interface Panel ................ 7 Main Screen ......................8 Parts and Accessories ..................... 9 Security Levels .......................
- Page 6 9190A Getting Started...
-
Page 7: Introduction
−95 °C to 140 °C. This manual includes information on how to set up and turn on the Product for the first time. For instructions on how to operate the Calibrator, see the 9190A Operators Manual on the CD-ROM. Contact Fluke Calibration To contact Fluke Calibration, call one of the following telephone numbers: •... -
Page 8: Safety Information
9190A Getting Started Safety Information A Warning identifies conditions and procedures that are dangerous to the user. A Caution identifies conditions and procedures that can cause damage to the Product or the equipment under test. Warning To prevent possible electrical shock, fire, or personal injury: •... - Page 9 Ultra-Cool Drywell Safety Information • Keep fingers behind the finger guards on the probes. • Do not exceed the Measurement Category (CAT) rating of the lowest rated individual component of a Product, probe, or accessory. See Table 1 for a list of symbols used in this manual and on the Calibrator. Table 1.
-
Page 10: Calibrator Features
9190A Getting Started Calibrator Features Table 2 identifies and describes the panels on the front of the Calibrator. Table 2. Front Panel 9190A Model 9190A-P Model 9190A 9190A gzs046.eps gzs001.eps Item Name Function Display and Control Panel Control panel and display. See page 5. -
Page 11: Display And Control Panel
Ultra-Cool Drywell Calibrator Features Display and Control Panel Table 3 shows and describes the function of each button on the Control Panel. Table 3. Display and Control Panel 9190A gzs002.eps Item Name Function Shows block temperature, measurements, status information, operating parameters, and softkey functions. -
Page 12: P Option Panel (Input Panel)
Function Reference Connect a Reference PRT probe to the Calibrator for use with the Thermometer Input reference thermometer function. See the 9190A Operators Manual for more information. (REF PRT) Connect a 4-20 mA transmitter to the Calibrator. The 4-20 mA 4-20 mA Connectors ... -
Page 13: Power And Remote Interface Panel
Ultra-Cool Drywell Calibrator Features Power and Remote Interface Panel Table 5 shows and describes the connectors and ports on the Power and Remote Interface Panel. Table 5. Power and Remote Interface Panel gzs004.eps Item Name Function Mains Power Cord Receptacle for the mains power cord. Use an AC mains supply ... -
Page 14: Main Screen
When the Calibrator turns on, the system initializes, does a self-check, then shows a startup screen that shows the model number and firmware version information. If the self- check finds an error, the error is shown on the Startup screen. Contact Fluke Calibration if an error shows on the Startup screen. -
Page 15: Calibrator Setup
Unpack the instrument carefully and examine it for any damage that could have occurred during shipment. If there is shipping damage, notify Fluke Calibration and the carrier immediately. Table 7 lists the equipment and the accessories that comes with the Calibrator. -
Page 16: Connect To Mains Power
1. Push the “I” side of the power switch on the front panel of the Calibrator. 2. Monitor the Startup screen for errors while the product turns on. If an error shows, contact Fluke Calibration. Change Language To change the display language: 1. -
Page 17: Security And Password
The information is then shown on the screen, but cannot be changed. Note The Calibrator does not have a password reset function. If the password is lost, contact Fluke Calibration for password reset assistance. Table 8. Security Levels Security Level Definition Protects the specific metrological information and calibration information settings. -
Page 18: Specifications
9190A Getting Started Specifications Base Unit Specifications Temperature Range at 23 °C ........ –95 °C to 140 °C (–139 °F to 284 °F) Display Accuracy ..........±0.2 °C Full Range Accuracy with External Reference ....±0.05 °C Full Range Stability ..............±0.015 °C Full Range Axial Uniformity at 40 mm (1.6 in) ....... -
Page 19: P Specifications
Ultra-Cool Drywell Specifications -P Specifications Built-in Reference Thermometer Readout Accuracy (4-Wire Reference Probe) ....±0.010 °C at –95 °C ±0.013 °C at –25 °C ±0.015 °C at 0 °C ±0.020 °C at 50 °C ±0.025 °C at 140 °C Reference Resistance Range....... 0 Ω to 400 Ω ..... - Page 20 9190A Getting Started...
