Electrical Measurement Module Kit with Docking Station
Introduction
The Electrical Measurement Module with Docking Station (the Product) is an accessory to allow electrical
measurements to be made from pressure Devices Under Test (DUT) such as transmitters, transducers, and more.
The Product includes an EMM300 Electrical Measurement Module and its dock, the DS70-KIT-EMM Docking Station
that enables connection of the Electrical Measurement Module (EMM) to a pressure calibrator. The EMM module
measures mA, V dc, and can supply 24 V loop power. It also provides basic analog trimming of HART devices.
How to Contact Fluke Calibration
To contact Fluke Calibration, call one of the following telephone numbers:
•
Technical Support USA: 1-877-355-3225
•
Calibration/Repair USA: 1-877-355-3225
•
Canada: 1-800-36-FLUKE (1-800-363-5853)
•
Europe: +31-40-2675-200
•
Japan: +81-3-6714-3114
•
Singapore: +65-6799-5566
•
China: +86-400-810-3435
•
Brazil: +55-11-3759-7600
•
Anywhere in the world: +1-425-446-6110
To see product information and download the latest manual supplements, visit Fluke Calibration's website at
www.flukecal.com.
To register your product, visit
5007312
PN
July 2018
©2018 Fluke Corporation. All rights reserved.
All product names are trademarks of their respective companies. Specifications are subject to change without notice.
Fluke Corporation
P.O. Box 9090
Everett, WA 98206-9090
U.S.A.
http://flukecal.com/register-product
Fluke Europe B.V.
P.O. Box 1186
5602 BD Eindhoven
The Netherlands
KIT-EMM300
.
ООО «Флюк СИАЙЭС»
125167, г. Москва, Ленинградский
проспект дом 37,
корпус 9, подъезд 4, 1 этаж
Instructions
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fluke Calibration KIT-EMM300
Summary of Contents for Fluke Calibration KIT-EMM300
- Page 1 • China: +86-400-810-3435 • Brazil: +55-11-3759-7600 • Anywhere in the world: +1-425-446-6110 To see product information and download the latest manual supplements, visit Fluke Calibration’s website at www.flukecal.com. To register your product, visit http://flukecal.com/register-product 5007312 July 2018 ©2018 Fluke Corporation. All rights reserved.
-
Page 2: Safety Information
KIT-EMM300 Instructions Safety Information A Warning identifies conditions and procedures that are dangerous to the user. A Caution identifies conditions and procedures that can cause damage to the Product or the equipment under test. WWarning To prevent possible electrical shock, fire, or personal injury: •... - Page 3 Electrical Measurement Module Kit with Docking Station The Product The Product Table 2 shows the Product. Table 2. The Product ifh01.eps Number Description Docking Station, DS70-KIT-EMM Electrical measurement Module, EMM300 Input Terminals Power Socket RS232 Connector CAN bus Connector...
- Page 4 KIT-EMM300 Instructions Set Up To set up the Product: 1. Connect the CAN bus cable to the Docking Station and to the CAN bus connector on the rear panel of the Pressure Controller. See Figure 2. 2. Connect the Test Leads from the EMM300 Input Terminals to the DUT connections, observing polarity.
- Page 5 Electrical Measurement Module Kit with Docking Station mA/V dc Operation mA/V dc Operation The EMM provides measurement of V dc and mA with or without 24 V loop power. To enable the mA/VDC function: 1. From the Controller Main screen, push EMM/HART on the left of the touchscreen. 2.
-
Page 6: Hart Operation
KIT-EMM300 Instructions HART Operation Highway Addressable Remote Transducer (HART) is an industry standard that defines the communications protocol between smart field devices and a control system that uses traditional 4-20 mA wiring. HART allows the technician to configure and adjust variables stored and used by the transmitter. The HART function of the Product allows for calibration and testing of many HART-enabled devices such as transmitters. - Page 7 Electrical Measurement Module Kit with Docking Station Pressure Transmitter Instructions iIfh02.eps Figure 2. Transmitter Connection...
- Page 8 KIT-EMM300 Instructions HART Tasks The HART tasks are explained in the subsequent sections. See Figure 3 for an overview of the menus. Zero TRIM 4mA TRIM 20mA Range Trim PV Zero Trim Current Output HART Trim by Re-Range Tasks Write LRV and URV...
- Page 9 Electrical Measurement Module Kit with Docking Station HART Tasks Trim PV Zero The Trim PV Zero command zeros the pressure sensor in a transmitter. The resulting offset must be within limits by each device. The span of Primary Variable remains constant. This command does not affect or interact with the Upper or Lower-Range values.
- Page 10 KIT-EMM300 Instructions Note Changing the LRV affects the URV. If the LRV should be tested against ATM, check the Set to ATM checkbox. When is Set to ATM is pushed, the LRV is non-editable. • URV - Configure the upper range value of transmitter.
-
Page 11: Write Message
Electrical Measurement Module Kit with Docking Station HART Tasks HART Diagnostics Some HART devices feature a self-test function that check various aspects of the transmitter such as the processor and memory when commanded. Not all HART devices have this feature. If the transmitter has this function, the controller sends the self-test command and shows the results of the self-test on the display. - Page 12 KIT-EMM300 Instructions Write Description To write the description (max 16 characters): Note This can also be changed in the HART Data menu. 1. Push HART Tasks on the HART menu. 2. Select Write Description. 3. Use the on-screen keyboard to enter the tag.
-
Page 13: Specifications
Electrical Measurement Module Kit with Docking Station Specifications Specifications Operating Temperature ......15 °C to 35 °C Storage Temperature ......-20 °C to +70 °C Electrical Measurement Module (EMM) Connection ......... Banana Jack, CAN bus, RS232 Maximum 30 V dc HART Communication and Functions HART Modes ........
