Fluke Calibration 525B Getting Started Manual

Temperature/pressure calibrator
Hide thumbs Also See for 525B:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
525B
Temperature/Pressure Calibrator
Getting Started Guide
PN 3064079
July 2012
© 2007, 2012 Fluke Corporation. All rights reserved. Printed in USA.
All product names are trademarks of their respective companies.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 525B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fluke Calibration 525B

Summary of Contents for Fluke Calibration 525B

  • Page 1 525B Temperature/Pressure Calibrator Getting Started Guide PN 3064079 July 2012 © 2007, 2012 Fluke Corporation. All rights reserved. Printed in USA. All product names are trademarks of their respective companies.
  • Page 2 LIMITED WARRANTY AND LIMITATION OF LIABILITY Each Fluke product is warranted to be free from defects in material and workmanship under normal use and service. The warranty period is one year and begins on the date of shipment. Parts, product repairs, and services are warranted for 90 days.

  • Page 3: Table Of Contents

    Table of Contents Title Page Introduction ......................1 Contacting Fluke ....................1 Standard Equipment ................... 2 Options and Accessories ..................2 Safety Information ..................... 2 Getting Acquainted with the Calibrator ............. 4 Input and Output Terminals ................4 Display Error Messages ................. 8 Rear Panel View ....................
  • Page 4 525B Getting Started Guide...
  • Page 5 List of Tables Table Title Page Summary of Input and Output Functions ............... 1 Symbols Used on the Calibrator ................3 Function Keys ......................6 Display Error Messages ..................8...
  • Page 6 525B Getting Started Guide...
  • Page 7 List of Figures Figure Title Page Input and Output Terminals and Connectors ............4 Pushbuttons ......................5 Calibrator Function Keys ..................6 Rear Panel View ..................... 9...
  • Page 8 525B Getting Started Guide...

  • Page 9: Introduction

    Temperature/Pressure Calibrator Introduction Your Fluke 525B Temperature/Pressure Calibrator (referred to as the Calibrator) is an instrument designed to meet the demands of your process tools calibration workload. In addition to the functions in Table 1, the Calibrator has the following features and functions.

  • Page 10: Standard Equipment

    The items listed below are included with your Calibrator. If the Calibrator is damaged or something is missing, contact the place of purchase immediately. For information on replacement parts or spares, see the replacement parts list in Chapter 6 of the 525B Users Manual.

  • Page 11: Symbols Used On The Calibrator

    Temperature/Pressure Calibrator Safety Information  Warning To avoid possible electric shock or personal injury, follow these guidelines: • Use the Calibrator only as specified in this manual, or the protection provided by the Calibrator might be impaired. • Inspect the Calibrator before using it. Do not use the Calibrator if it appears damaged.

  • Page 12: Getting Acquainted With The Calibrator

    525B Getting Started Guide Getting Acquainted with the Calibrator Input and Output Terminals Figure 1 shows the Calibrator input and output terminals and explains their use. VOLTS 100mA MAX OUTPUT STBY VOLTS TYPE 100V MAX UNITS INPUT/OUTPUT 20V PK OUTPUT...
  • Page 13 Temperature/Pressure Calibrator Getting Acquainted with the Calibrator Using the Keys Figure 2 shows the Calibrator pushbuttons and explains their use. Other function keys are shown in Figure 3 and described in Table 3. STBY VOLTS TYPE UNITS OUTPUT INPUT ZERO SHIFT SETUP C / F...

  • Page 14: Function Keys

    525B Getting Started Guide STBY VOLTS TYPE UNITS OUTPUT INPUT ZERO SHIFT SETUP C / F RECALL AUTOSET RNG LOCK LOCAL • ENTER ans11f.eps Figure 3. Calibrator Function Keys Table 3. Function Keys Name Description  RNG LOCK Activates/deactivates the autorange feature of the Calibrator in Voltage ...
  • Page 15 Temperature/Pressure Calibrator Getting Acquainted with the Calibrator Table 3. Function Keys (cont) Name Description  INPUT Selects Input mode.   ZERO Zeros the pressure module reading when in Pressure Measurement mode.  Zeros the thermocouple TC mV/°C offset when in TC Measurement mode. ...

  • Page 16: Display Error Messages

    525B Getting Started Guide Display Error Messages The following informative messages may appear on the front panel display. An explanation of each message is also provided. Table 4. Display Error Messages Message Explanation OVER RANGE May be displayed in all output modes if you enter a value from the front panel keypad that exceeds the output range of the function.

  • Page 17: Rear Panel View

     Service port used to download new firmware to the Calibrator.  The IEEE-488 connector is a standard parallel interface for operating the 525B in remote control as a talker/listener on the IEEE-488 bus.  The RS-232 connector is used for serial remote control of the 525B.

  • Page 18: General Specifications

    525B Getting Started Guide General Specifications Warm up time ............Twice the time since last warmed up, to a maximum of 30 minutes. Settling time ............Less than 5 seconds for all functions and ranges except as noted. Standard interface ..........RS-232, IEEE-488 (GPIB) Temperature performance Operating ............

  • Page 19: Dc Current Specifications, Output

    Temperature/Pressure Calibrator Electrical Specifications Noise Ranges Bandwidth 0.1 to 10 Hz Bandwidth 10 Hz to 10 kHz ± (ppm of output + μV p-p) (μV rms) 1 μV 6 μV 0 to 100.000 mV 10 μV 60 μV 0 to 1.00000 V 100 μV 600 μV 0 to 10.0000 V...

  • Page 20: Thermocouple Specification, Output And Input

    525B Getting Started Guide Thermocouple Specification, Output and Input Absolute Uncertainty tcal ± 5 °C, ± (°C) Range (°C) TC Type Output/Input Minimum Maximum 90 days 1 year 600 °C 800 °C 0.42 °C 0.46 °C 800 °C 1000 °C 0.39 °C...

  • Page 21: Rtd And Thermistor Specification, Output

    Temperature/Pressure Calibrator Electrical Specifications RTD and Thermistor Specification, Output Absolute Uncertainty Range (°C) tcal ± 5 °C, ± (°C) RTD Type Minimum Maximum 90 days 1 year -200 °C -80 °C 0.03 °C 0.04 °C -80 °C 0 °C 0.04 °C 0.05 °C 0 °C 100 °C...

  • Page 22: Rtd And Thermistor Specification, Input

    525B Getting Started Guide RTD and Thermistor Specification, Input Absolute Uncertainty Range (°C) tcal ± 5 °C, ± (°C) RTD Type Minimum Maximum 90 days 1 year -200 °C -80 °C 0.011 °C 0.012 °C -80 °C 0 °C 0.018 °C 0.020 °C...

  • Page 23: Pressure Measurement

    Temperature/Pressure Calibrator Pressure Measurement Pressure Measurement The Calibrator can accept either the Fluke 700 or 525A-P series pressure modules. Pressure modules plug directly into the front panel Lemo connector with the Calibrator firmware autodetecting the type and value of the module you are attaching.
  • Page 24 525B Getting Started Guide...
