  • Page 1 ® Owner’s Manual...

  • Page 2: Symbol Legend

    Vis venligst hensyn til miljøet ved at levere produktet til det nærmeste genbrugsanlæg, når det ikke længere fungerer. Por favor, assuma responsabilidade ambiental, reciclando este produto em suas instalações de reciclagem no final de sua vida útil. 800.342.8968 www.easystand.com...

  • Page 3: Table Of Contents

    EasyStand Evolv Assembly . . . . . . . . . . . . . . . . . . 3...

  • Page 4: Introduction

    Altimate Medical, Inc., at 800-342-8968 or 507-697-6393. It is necessary to inspect the EasyStand Evolv at least weekly to ensure it is in safe operating condition. EasyStand adjustments that are listed in the product owner’s manual can be made by the operator by following the instructions for use.

  • Page 5: Safety Precautions

    • If the EasyStand is being used in the home environment, please inspect the unit prior to each use to ensure there is no damage or unexpected wear to the EasyStand that may have been caused unintentionally by pets, pests or children.

  • Page 6: Easystand Evolv Assembly

    EasyStand Evolv Assembly ® ® Videos of EasyStand Evolv assembly & fitting can be viewed at www.easystand.com/videos FIG. 3B FIG. 3A FIG. 1 FIG. 2 Seat Assembly FIG. 2B Front Frame page 3 EasyStand Evolv Assembly...
  • Page 7 For Mobile assembly refer to p. 11 If the Evolv XT was ordered, the unit will be fully assembled except for the tray and back option. Refer to p. 18 for the back option assembly, p. 23 for the tray assembly and p. 9 for the Shadow Tray.
  • Page 8 FIG. 5 FIG. 6 FIG. 4 page 5 EasyStand Evolv Assembly...
  • Page 9 FIG . 6- Install the seat onto the seat assembly after all other options are added. For easier installation, pump the seat half- way up. Start all four bolts first, then tighten securely. For Evolv adjustments, see pp . 27-30 . Evolv E3 page 6 EasyStand Evolv Assembly...

  • Page 10: Swing-Away Front

    Swing-Away Front Assembly Swing-Away Front for Shadow Tray Tray FIG. 8 FIG. 9 Tray Frame FIG. 7 FIG. 8 H-Frame Kneepad Bracket Crossbar FIG. 7 Front Caster Frame page 7 Swing-Away Front Assembly...
  • Page 11 Caution: Collar and pins must be securely in place before the user transitions into the standing position. For Evolv adjustments, see p . 27 . FIG. 9 page 8 Swing-Away Front Assembly...

  • Page 12: Shadow Tray

    Shadow Tray Assembly ® Shadow Tray Bracket Set-up End Cap Knobs FIG . 10- On the support arm, remove the plastic FIG . 13- The knobs on the end of the support arm should be exposed. Rotate the arm down to 90˚. Lock the plunger bag with two mounting bolts and a silver pin.
  • Page 13 FIG . 15- To install the support arm, first remove the nut from the pre-assembled bolt on the arm, leaving the bolt and the two halves of the fitting (one plastic and one metal) in place on the tube. Thread the bolt into the hip plate, as shown in Fig.

  • Page 14: Mobile

    Mobile Assembly FIG. 20 FIG. 18 FIG. 19 Mobile Bracket Mobile Bracket Knee pad Bracket FIG. 22 Mobile Assembly Wheel Frame FIG. 21 page 11 Mobile Assembly...
  • Page 15 FIG. 18 Front Frame FIG . 18- Place the front frame onto the wheel frame. Line up the two bolts with the holes on the wheel frame, start both bolts before tightening securely. Wheel Frame FIG . 19- Attach the casters to the rear base frame. Tighten securely using the provided wrench.

  • Page 16: Pow'r Up Lift Option

    Pow’r Up Lift Charging the Battery The EasyStand Evolv Pow’r Up Lift uses two 12 volt sealed lead batteries rated at 2.9 amps each. An EasyStand Evolv can be lifted approximately 100 times on one full battery charge. An audible alarm will sound when the battery is low.

  • Page 17: Battery Replacement

    FIG . C2- If no Mobile Option was ordered, assemble the hand control as illustrated in Fig. C2. CAUTION: The Evolv Pow’r Up Option is not designed for continuous use. Duty Cycle 5% Max, 1 min. / 19 min. Raising the Lift - Press the UP (arrow up) button on the hand control to lift the seat.
  • Page 18 Guidance and Manufacturer’s Declaration - Electromagnetic Emissions The EasyStand Evolv is intended for use in the electromagnetic environment specified below. The customer or the user of the EasyStand Evolv should assure that it is used in such an environment. Compliance...
  • Page 19 Guidance and Manufacturer’s Declaration - Electromagnetic Immunity The EasyStand Evolv is intended for use in the electromagnetic environment specified below. The customer or the user of the EasyStand Evolv should assure that it is used in such an environment. Immunity Test...
  • Page 20 RF communications equipment and the EasyStand Evolv The EasyStand Evolv is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the EasyStand Evolv can help prevent electromagnetic interference by...

  • Page 21: Option Assembly

    Option Assembly Back Option PNG50062, PNG50066, PNG50067, PNG50068 To assemble the back option, slide the back assembly into the seat assembly as shown. Tighten secure- ly with bolts provided, then add the swing-away arms. Remove the nut and lock washer from the arm. Place the arm onto the unit keeping the arm assembly together.
  • Page 22 Cane Back Cane Back 16”Wx21”H 18”Wx21”H PNG50492 PNG50493 To assemble the cane back option, slide the back assembly into the seat assembly as shown. Tighten securely with bolts provided. Standard Foot Straps PNG30030 Secure Foot Straps PNG30031 Head Support-Short Head Support-Tall 21”-30”H 25”-34”H PNG50240...
  • Page 23 Remove the nuts and bolts from the pump handle. Insert the handle onto the pump. Line up holes and insert bolts, place nuts onto bolts. Tighten securely. Standard Standard Adjustable/ T-Style Quad Grip Actuator Actuator Removable Handle Handle Handle Left Handle Right Handle Universal Left/Right Extension...
  • Page 24 High Mount Chest Vest Bracket High Mount Chest with Head Support Vest Bracket PNG11212 PNG11212 If you ordered the high mount chest vest bracket and head support, place the head support bracket and the high mount chest vest bracket on the unit as shown.
  • Page 25 Large Contoured Chest Pad PNG30000 Remove bolts from chest Oversized Tray pad and place onto tray. PNG50194 Tighten bolts securely. Chest Strap Small-PNG50192 Large-PNG50193 Padded Tray Cover PNG30295 Y-Style Chest Vest Medium-PNG30171 X-Style Large-PNG30021 Chest Vest Medium-PNG30170 Large-PNG30056 page 22 Option Assembly...
  • Page 26 Swing-Away Front Place tray onto the tray post, insert nut into Angle Adjustable Tray slot and bolt into hole, tighten securely. Black Molded PNG50490 Swing-Away Front Angle Adjustable Clear Acrylic Tray PNG50489 Swing-Away Front Angle Adjustable Oversized Clear Acrylic Tray PNG50410 Angle Adjustable Tray - Clear Acrylic...
  • Page 27 Front Swivel Casters for Swing-Away Front Evolv Medium/Large-PNG50314 FIG . A- Place a block of wood under the unit to raise the caster frame. Place hardware onto the FIG . A unit as shown- bolt, washer, frame, spacer, cast- er assembly, washer, then nut.
  • Page 28 Independent Roho ® Swing-Away Front Independent Knee pads PNG50385 Independent Knees PNG50425 Knee pads PNG50384 Curve Up Remove ratchet handle and hardware from the knee bracket. Place onto the column in the order as shown. Make sure spacer is placed between the two steel brackets. Leave the bolt just loose enough to allow bracket to slide freely.
  • Page 29 Rotating Seat Roho Seat ® Evolv Medium-PNG50324 Evolv Medium-PNG30183 Evolv Large/XT-PNG50318 Evolv Large/XT-PNG30023 Push the lever under the seat to rotate. Ensure seat is locked into position prior to transferring. Install the seat onto the seat assembly after all the other options are added.

  • Page 30: Adjusting The Evolv

    Make sure the foot plate notch is positioned in one of the four slots.* Place the bolt back into the foot plate once the desired position is reached. *Available on the Evolv E3 if ordered with multi-adjustable foot plates. FIG. I Knee pad FIG .
  • Page 31 Please check for fit and interference by bringing the unit to the full standing position and back to sitting again without a user seated in the unit, as the pads may not work perfectly in all positions. page 28 Adjusting the Evolv...
  • Page 32 Move the front pad to the user’s desired position and tight- en the clamp. Caution: While lowering the tray height, keep hands clear of the area underneath the tray. page 29 Adjusting the Evolv...

  • Page 33: Shadow Tray Adjustments

    Shadow Tray Adjustments ® Tray Depth Adjustment Chest Pad Height Adjustment FIG. B Support Locking Mechanism FIG. A Set Screw FIG . A- To adjust chest pad height, loosen knob and move to desired position. Tighten securely. FIG . B- To adjust the depth of the front pad and tray, loosen the knob located below the tray.

  • Page 34: Evolv Options & Parts Detail

    Evolv Options & Parts Detail (front) ® page 31 Evolv Options & Parts Detail...
  • Page 35 NG50042 NG50247 Black Molded Tray Assembly NG50372 Mobile Clear Tray Assembly NG30295 Padded Tray Cover Clear Mobile Tray NG20092 H-Frame Clear Tray NG50489 NG50490 H-Frame Black Molded Tray NG50410 H-Frame Oversized Clear Tray page 32 Evolv Options & Parts Detail...
  • Page 36 Evolv Options & Parts Detail (rear) ® page 33 Evolv Options & Parts Detail...
  • Page 37 NG50040 Push Handles NG50037 Head Support 24”-33”H NG50240 Head Support 21”-30”H NG11212 High Mount Chest Vest Bracket NG50176 Lateral Supports 12”-18”W NG50224 Lateral Supports 9”-15”W NG50198 Hip Supports Large NG50161 Hip Supports Medium page 34 Evolv Options & Parts Detail...

  • Page 38: Perfect Fit Guide

    Perfect Fit Guide step one - measure Before transferring into the Evolv, measure for approximate (A) seat depth and seat to (B) foot plate settings. step two - seat depth Use the above measurement (A) to adjust the seat depth on the stander, measure from the front of the seat to the back.

  • Page 39: Transferring

    There are also a variety of options that can be added to the Evolv to help make transferring more manageable. For proper transfer techniques, please seek professional advice from a therapist or physician.

  • Page 40: Standing

    15-25 long strokes. The seat will slowly rise to the standing position. Remember the seat can be stopped anywhere between sitting and standing. Caution: Never make adjustments to the EasyStand while a user is in the standing position. Return to the Seated Position Move and hold the pump handle toward the rear until the desired position is reached.

  • Page 41: Maintenance

    EasyStand will be needed. • Do not exert excessive force on the pump handle or use the pump handle to move an EasyStand. This may cause damage to the pump handle and/or the pump mechanism and will void any warranty.

  • Page 42: Troubleshooting

    My EasyStand will not go into the full standing position: As of June 2011 the EasyStand (manual hydraulic pump only) is equipped with a safety feature to prevent over travel of the lifting/following arm mechanism in the event the back angle is improperly adjusted to exceed the recommended angle.

  • Page 43: Limited Warranty

    Limited Warranty This warranty is extended only to the original purchaser/customer (or supplier non consumer who does not buy or resell). Altimate Medical, Inc., warrants the EasyStand Evolv against defects in materials and workmanship as listed below. • Steel Frames - 5 year warranty •...
  • Page 44 Morton, MN 56270 USA Toll Free: 800.342.8968 or 507.697.6393 Fax Free: 877.342.8968 or 507.697.6900 email: info@easystand.com www.easystand.com Standing technology should only be used under the guidance of a physician with recommendations for standing program protocol and any medical precautions. Standing programs should be monitored by the attending therapist. Altimate Medical maintains a policy of continual product improvement and reserves the right to change features, specifications, and prices without prior notification.
