14 Technical data

Power supply
Power consumption during normal operation: max. 5W
Power consumption when on standby:
Reception frequencies:
Music output
Environmental conditions:
Relative humidity:
Temperature:
Dimensions:

15 Installation

The Digitradio UP1 is comprised of the following components:
1 Recessed socket (not included in the scope of supply)
2 Radio unit
3 Speaker
4 Frame
5 Speaker cover
6 Radio operating unit
AC 100-240V, 50~60Hz
< 1W
DAB/DAB+ 174.928-239.200 MHz
FM: 87.5-108 MHz
2W RMS
5% ~ 90%
0 - 40°C
152mm x 81mm x 48mm
