Front Panel

The Thecus N8800's front panel has the device's controls, indicators, and hard
disk trays:
Front Panel
Item
1.Power Button
2.Power LED
3.Reboot Button
4.System fan
alarm LED
5. Mute button
6.USB Port
7.Up Button
▲
8.Down Button
▼
↵
9.Enter Button
10.Escape Button
ESC
Description
• Power on/off N8800
• Solid green: System is power on.
• Press to system reboot
• Solid red: system fan failure notification
• Mute the system fan alarm.
• USB 2.0 port for compatible USB devices, such as USB disks,
USB printers, and USB wireless dongles*
Note: For supported USB wireless dongles, please contact
http://esupport.thecus.com/support
• Push to scroll up when using the LCD display
• Push to enter USB copy operation screen
• Push to enter LCD operate password for basic system setting
• Push to leave the current LCD menu
