RAID 1
RAID 5
RAID 6
RAID 10
WARNING

RAID Configuration

Using RAID Settings, you can select stripe size, choose which disks are RAID
disks or the Spare Disk. .
RAID Configurations
Item
RAID
Master RAID
Disk No.
Capacity (MB)
Model
Status
Member
Spare
Stripe Size
Used Percentage
Apply
Remove
Back
Expand
Migration

Creating a RAID

To create a RAID volume, follow the steps below:
performance but not data safety. RAID 0 requires a minimum of
2 disks.
Offers disk mirroring. Provides twice the read rate of single
disks, but same write rate. RAID 1 requires a minimum of 2
disks.
Data striping and stripe error correction information provided.
RAID 5 requires a minimum of 3 disks. RAID 5 can sustain one
failed disk.
Two independent parity computations must be used in order to
provide protection against double disk failure. Two different
algorithms are employed to achieve this purpose. RAID 6
requires a minimum of 4 disks. RAID 6 can sustain two failed
disks.
RAID 10 has high reliability and high performance. RAID 10 is
implemented as a striped array whose segments are RAID 1
arrays. It has the fault tolerance of RAID 1 and the performance
of RAID 0. RAID 10 requires 4 disks. RAID 10 can sustain two
failed disks.
If the administrator improperly removes a hard disk that should not be
removed when RAID status is Degraded, all data will be lost.
Description
Check the boxes of the hard drives you wish to add to the
storage volume.
Check a box to designate this as the Master RAID volume. See
the NOTE below for more information.
Number assigned to the installed hard disks.
Capacity of the installed hard disks.
Model number of the installed hard disks.
Status of the installed hard disks.
If this is checked, current hard disk is a part of a RAID volume.
If this is checked, current hard disk is designated as a spare for
a RAID volume.
This sets the stripe size to maximize performance of sequential
files in a storage volume. Keep the 64K setting unless you
require a special file storage layout in the storage volume. A
larger stripe size is better for large files.
The percentage of the RAID volume that will be used to store
data.
Press this button to configure a file system and create the RAID
storage volume.
Click to remove the RAID volume. All user data, iSCSI, and
Target USB data will be removed.
Press this button to exit without saving changes.
Press this button to configure a file system and create the RAID
storage volume.
Press this button to migrate RAID level.
