PAG PAGlink 9710 Instruction Leaflet

Micro Charger / Model 9710
Instruction Leaflet
Safety
1.1 This leaflet contains important safety and operating instructions.
Please read these fully and note all warnings before using the
charger. Please follow all instructions and retain this leaflet for
future reference.
1.2 PAG chargers are not intended for any use other than the charging
of batteries as detailed in 'Specification'.
1.3 IMPORTANT: Use only on AC supplies 100-240V, 50/60Hz.
Supply connection to the charger should be made using only the
Power Supply Unit and plug supplied with this equipment.
1.4 Protect the power cord from being walked on or pinched. Unplug
this apparatus during lightning storms or when unused for long
periods of time.
1.5 WARNING: Indoor use only. To reduce the risk of fire or electric
shock, do not expose this apparatus to rain or moisture.
1.6 Although the charger is reverse polarity protected, extreme care
should always be taken not to short circuit the battery itself.
Rechargeable batteries can deliver power at a very high rate, and
short circuiting even a partially charged battery could result in a
fire or personal injury. PAG supplies a range of connector leads for
most charging requirements, and does not accept responsibility
for any other form of charging connection.
1.7 Do not disassemble the charger. There are no user-serviceable parts
inside. Incorrect reassembly may result in a safety hazard.
1.8 Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such as
the supply cord or plug, when the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
In this event you should seek advice from your PAG dealer or the
nearest PAG Authorised Service Centre by visiting paguk.com or
direct from PAG in the UK by calling +44 (0)20 8543 3131.
Specification
2.1 Model No. 9710
2.2 Range of Batteries Charged:
The PAGlink Micro Charger is designed for charging the following
PAGlink batteries, individually or linked:
• Model 9303 PAGlink PL96e
• Model 9304 PAGlink PL96T
• Model 9308 PAGlink PL150e
• Model 9309 PAGlink PL150T
It can also be used to charge the following batteries:
• Model 9307V PAG L90 Slim
• Model 9310V PAG L95e/L96e
• Model 9305V PAG L96T
• Model 9360 PAG L95
• Sony V-Mount Li-Ion
2.3 Battery Connections:
V-Mount connector.
2.4 Main Charge Program:
Li-Ion voltage-charge program.
2.5 Recovery Charge:
This special program will automatically recover a PAG Li-Ion
battery where the output has been shut down.
2.6 Self Test Program:
The internal microprocessor constantly monitors the battery under
charge or process as well as the operation of the charger's own
functions which will be shut down to a safe condition should any
of the tests fail.
2.7 AC Mains Input:
100-240V ~ autoselected. Frequency 50-60 Hz. Maximum power
consumption 35W.
2.8 Output Protection:
Charger protected against short circuit and open circuit.
2.9 AC Mains Failure Protection:
Should mains failure occur during a charging program, or whilst
the charger is connected, it will shut down to a safe condition.
2.10 User Interface:
LED indication of an absent battery, battery charging, charging
complete and a faulty battery is provided by the charger. Battery
state of charge is indicated by the battery's own capacity
indicator. The charger is fully automatic in operation and no user
controls are provided.
2.11 Operating Temperature Range:
0ºC to +40ºC (+32ºF to +104ºF).
2.12 Overall Dimensions / Weight:
110 x 87 x 58mm (boxed) / 200g.
2.13 Typical Battery Charging Times:
These charge times are for fully-discharged 96Wh batteries to
fully-charged. 150Wh batteries will take 50% longer.
No. of Batteries
1
2
3
4
Installation
3.1 PAGlink Micro Chargers are supplied with an AC to DC power supply
unit conforming to: EN60950-1, EN55022 & EN55024.
AC supply connection to the charger should be made using only
the Power Supply Unit and connector (plug) included with this
equipment. The following connectors are available from PAG:
• Model 9710U U K
• Model 9710E Europe
• Model 9710J Japan/USA
• Model 9710A Australia
3.2 The PAGlink Micro Charger PSU is designed for use on AC supplies
worldwide, and automatically accept supplies in the range 100-
240V ~ autoselected. Mains supply frequency must be in the range
50-60Hz.
3.3 PAGlink Micro Charger Model 9710 may be powered from a 12V
vehicle battery using PAG Vehicle Battery-Power Converter, Model
No. 9775.
3.4 PAG TECHNICAL INFORMATION:
For further technical information, please contact an authorised
PAG Service Centre. Visit the PAG website at paguk.com/agents
to discover your nearest point of contact, or contact PAG Ltd.
in the UK: +44 (0)20 8543 3131, or support@paguk.com.
Charge Time
3 hrs 15 mins
7 hrs 15 mins
11 hrs 15 mins
15 hrs
