3.5.2 WATER DRAIN (EXCLUDING MODEL 224854)
• There is a water drain at the bottom of the oven
and it must be connected with a rigid pipe whose
diameter may not be lower than the diameter of
the water drain.
• To facilitate drainage, the pipe must be placed at
least 20 cm below its connection point.
3.5.3 CONNECTION TO POWER SUPPLY
• Make sure the appliance is fit for operation at the
intended power supply voltage and frequency.
• Check the details on the rating plate of the ap-
pliance.
• Install, in front of the appliance, in a readily ac-
cessible place, a residual current device with a
between-contacts aperture which guarantees
complete disconnection in the event of a class 3
surge.
3.5.4 EARTHING AND EQUIPOTENTIAL BONDING
• Connect the electrical appliance to an effective
EN
earth conductor. Bind the earth wire to the ter-
minal marked
board.
3.6 GETTING STARTED
After installation or maintenance, check if the appliance operates correctly. If there are problems in operation,
go to "Troubleshooting".
ELECTRICAL APPLIANCE
Start the appliance in accordance with the user's
manual and the warnings presented in the "OPE-
RATING INSTRUCTIONS" section and check:
• the value of the current of each phase.
8
next to the line input terminal
• If the water drain is clogged, this may cause the
release of unpleasant smell into the oven cham-
ber or the leaking of steam through the door, so
the connection to the sewerage requires a so-
-called air gap according to the Polish standard
PN.
• Use a flexible power lead with rubber insulation
and properties not worse than type H05RN-F ca-
bles.
• Connect the power lead to the terminal board as
shown in the electrical diagram supplied with the
appliance.
• Secure the power lead with a cable gland.
• Protect the power lead outside the appliance with
a metal or plastic cable duct.
• Connect the metal casing of the electrical ap-
pliance to an equipotential bonding system. Bind
the wire to the terminal marked
de of the rear panel.
• if the heaters engage properly,
• if the indicators light up correctly,
• if the motor operates correctly.
on the outsi-
