6.2 TROUBLESHOOTING
Problem
The oven does not heat up
The heating cannot be controlled.
6.3 REPLACEMENT OF COMPONENTS
Only an authorised, licensed and trained service personnel is allowed to replace any components.

7. TECHNICAL PARAMETERS

MODEL
Capacity
Standard equipment
Tray support spacing [mm]
External dimension [mm]
Fan quantity
Fan speed [RPM.]
Temperature range [°C]
Timer (min.)
Humidification
Power [kW]
Tension [V]
Frequency [Hz]
Net weight [kg]
The manufacturer and dealer is not liable for any inaccuracies due to printing errors or transcription,
in this manual. In line with our policy of continuous improvement products, we reserve the right to
make modification of the product, packaging and specifications contained in the Documentation without
prior notice.
Causes
The temperature control thermostat is damaged.
The heaters are damaged.
The safety thermal breaker has been activated.
Apply RESET (This may only be done by qualified and authorised service
personnel).
The temperature control thermostat is damaged.
224854 224861
4x 600x400 mm 4x GN 1/1
1 grid 600x400 mm 1 grid GN 1/1
70
724x730x(H)598 825x685x(H)560
2
non-reversibles reversibles
2800 2800
10-280 10-280
1-120 1-120
Direct, manual, Direct, manual,
controlled by a controlled by a
button button
3,3
230 230
50
52
224878
6x GN 1/1
1 grid GN 1/1
75 75
833x710x(H)710
2 2
reversibles
2800
10-280
1-120
Direct, manual,
controlled by a
button
3,5 7,7
400
50 50
59 85
224885
10x GN 1/1
1 grid GN 1/1
EN
75
833x710x(H)1010
3
reversibles
2800
10-280
1-120
Direct,
manual, controlled by
a button
11,5
400
50
125
