- Page 1 ASSEMBLY , INSTALLATION AND OPERATING INSTRUCTIONS FOR GTR SERIES CABINET/TROLLEY SHELVES MODELS: GTR3, GTR4, GTR5, GTR6. GTR3 SS, GTR4 SS, GTR5 SS, GTR6 SS. GTR3 S, GTR4 S, GTR5 S, GTR6 S. IMPORTANT – PLEASE READ ALL INSTRUCTIONS BEFORE YOU ASSEMBLE, INSTALL OR OPERATE THIS APPLIANCE.
- Page 2 CONTENTS CABINET/TROLLEY SHELVES ASSEMBLY INSTRUCTIONS WARRANTY...
- Page 3 CABINET/TROLLEY SHELVES ASSEMBLY INSTRUCTIONS TOOLS REQUIRED FOR ASSEMBLY • Remove any plastic film protecting or covering any parts of the Shelves before 10mm spanner assembly. • Cut away any packaging or cable ties that Phillips head screwdriver may be holding components in place. •...
- Page 4 CABINET/ TROLLEY SHELVE ASSEMBLY 2. Now using the 6mm bolts, Spacers, washer and nuts, attach the side shelf arms onto the 1. The shelf brackets are attached with 4 long brackets as per photos. SS bolts through the counter sink holes in First push the bolt through the angle bracket the sides of the cabinet and go all the way and shelf arm bracket then from the inside,...
- Page 5 3. Insert the removable shelves into the locating points on the shelf arm as per photo below. 4. Use the small 4mm bolts to level the shelves if necessary, as per photo.
- Page 6 WARRANTY TUCKER GTR SHELVES WARRANTY 5. Proof of purchase together with this warranty must be provided to verify purchase date and establish the warranty period. Only WARRANTY PERIOD the original purchaser is covered under this 10 years Stainless steel body warranty.
- Page 7 TUCKER AUSTRALIA PTY LTD. 138 Silverwater Road Silverwater NSW 2128 AUSTRALIA. PHONE: (+612) 9748 8368 FAX: (+612) 9748 8138 WEB SITE: www.tuckerbbq.com.au EMAIL: mail@tuckerbbq.com.au...
