- Page 1 ASSEMBLY , INSTALLATION AND OPERATING INSTRUCTIONS CHARCOAL DELUXE BUILT-IN BARBECUE IMPORTANT – PLEASE READ ALL INSTRUCTIONS BEFORE YOU ASSEMBLE, INSTALL OR OPERATE THIS APPLIANCE. V20.05.2021...
-
Page 2: Table Of Contents
CONTENTS IMPORTANT SAFETY INSTRUCTIONS BARBECUE ASSEMBLY INSTRUCTIONS INSTALLATION INSTRUCTIONS & WARNINGS DIMENSIONS OPERATING INSTRUCTIONS HOW TO LIGHT UP THE CHARCOAL DELUXE BARBECUE COOKING HINTS SERVICE & MAINTENANCE WARRANTY V20.05.2021... -
Page 3: Important Safety Instructions
BBQ. • Placing too much charcoal in the barbecue • Tucker Charcoal Deluxe Barbecues are is highly dangerous and can result in a huge made for outdoor use only. fire that can damage the BBQ. -
Page 4: Barbecue Assembly Instructions
Cut away any packaging or cable ties that may be holding components in place. • Check you have all the correct components as listed in this Page. BARBECUE PARTS Charcoal Deluxe Barbecue Body Cooking Grills Charcoal Deluxe Charcoal Tray Charcoal Deluxe Ash Tray... - Page 5 Charcoal Deluxe Barbecue Assembly Tucker Charcoal Deluxe BBQs cannot be 1. Remove the Charcoal Deluxe Barbecue from the installed into combustible material unless you box and remove any plastic film or packaging install it with a Tucker Insulation Jacket. that protects the barbecue in the box.
-
Page 6: Installation Instructions & Warnings
• Within a partial enclosure that includes an The Charcoal Deluxe BBQ is very hot when it is in use. overhead cover and more than two walls, the DO NOT use the BBQ up against or closer than 1m to following shall apply. - Page 7 DIAGRAMMATICAL REPRESENTATIONS OF FIGURE 4 OUTDOOR AREA –EXAMPLE 4 OUTDOOR AREAS The following figures are diagrammatical representations of outdoor areas. The areas used in the figures below are examples – the same principles apply to any other shaped area. FIGURE F1 – OUTDOOR AREA – EXAMPLE 1 Open side at least 25% 30% or more in total of of total wall area.
-
Page 8: Dimensions
DIMENSIONS DIMENSIONS OF CHARCOAL DELUXE BUITL-IN BARBECUE 670mm 540mm 525mm 280mm 540mm 260mm 860mm 535mm 40mm 555mm NOTE 860mm When roasting hood is shut, handle will pass front panel by 15mm this makes the hood to be 570mm deep. When hood is open, it will overhang the back panel by 30mm. - Page 9 CHARCOAL DELUXE BARBECUE CUT OUT DIMENSIONS FOR NON COMBUSTIBLE MATERIAL INSTALLATIONS. (i.e. brickwork) 565-600mm 870mm 260mm If the surrounding wall surfaces above the BBQs cooking surface are combustible, then the following clearances must be adhered to. Clearances above BBQ cooking surface to...
-
Page 10: Operating Instructions
1. We recommend you light a small amount of charcoal, (1 kg) in the charcoal tray. Once the charcoal is alight, push it around the base of the Warning: NEVER use the Charcoal Deluxe BBQ charcoal tray using long tongs so as to cure in indoors. - Page 11 Never use more than 2 kg of charcoal in the charcoal tray of the firebox at any one time. Over firing the BBQ with too much charcoal will cause damage to the BBQ itself and/or your property. If BBQ is over fired, it can cause discolouring. The stainless steel surface will change to a bronze colour if it is overheated.
-
Page 12: How To Light Up The Charcoal Deluxe Barbecue
HOW TO LIGHT UP THE CHARCOAL DELUXE BARBECUE CHOOSING THE RIGHT FUEL LIGHTING THE CHARCOAL BARBECUE FOR THE BARBECUE 1. Remove the stainless steel cooking grills and place some crumpled up paper in the base of There are many varieties of charcoal, both local and the coal tray. - Page 13 4. Leave the fire to burn for 10 minutes or so or until the paper and kindling are all burnt and the charcoal is a white-grey colour. 5. Once the charcoal is ready, spread it out below the area of the BBQ you intend to use. Then replace the stainless steel cooking grills and wait another 5 minutes or so for the grills to heat up and you can begin to cook.
- Page 14 Charcoal Deluxe Barbecues are not designed to be heaters or braziers, running them like so could damage the BBQ. The rear wall behind a Tucker Charcoal Deluxe BBQ must be non-combustible. DO NOT use water to put the fire out or it will damage the BBQ.
-
Page 15: Cooking Hints
COOKING HINTS COOKING WITH CHARCOAL ADDING FLAVOUR TO YOUR COOKING People love the traditional method of cooking over When using charcoal barbecues, most people like to charcoal. The idea is to cook directly above the experiment with smoking their meats or fish. charcoal so the oil dripping down infusing the meat You can get a variety of different wood chunks or with the flavour. -
Page 16: Service & Maintenance
SERVICE & MAINTENANCE TAKE CARE OF THE APPLIANCE CLEAN THE BBQ 1. Clean your BBQ regularly. Always check the ash/ 1. Before each use, remove any accumulated grease tray before use. Grease and fat fires are grease and other cooking residue. Fat/grease not covered by the warranty. -
Page 17: Warranty
WARRANTY TUCKER CHARCOAL DELUXE BARBECUE 6. Where this warranty is inconsistent with any state WARRANTY laws, the rights of the purchaser shall prevail. 7. Parts installed from other manufacturer’s products will nullify this warranty. WARRANTY PERIOD Stainless steel body 10 years... - Page 18 NOTES...
- Page 19 TUCKER AUSTRALIA PTY LTD. 138 Silverwater Road Silverwater NSW 2128 AUSTRALIA. PHONE: (+612) 9748 8368 FAX: (+612) 9748 8138 WEB SITE: www.tuckerbbq.com.au EMAIL: mail@tuckerbbq.com.au...
