Flamerite Fires Valliant Instructions For Use

Where a chimney is not blocked off completely it will cause the heater to cut out during use.
The inset dimensions for Hole in the Wall: depth 10cm, height 56cm and width 54cm. To prevent the fire from being pulled over it must be
secured into place. The height at which you wish to fix the fire to the wall is up to you, though we recommend 60cm from the floor to the bottom
of the fire.
Using as a Hang on the Wall.
The wall bracket should be fixed to the wall with the hooks facing upward and outward (fig.1). The height at which you fix the fire to the wall
should be no less than 60cm from the floor to the bottom of the fire. Once the bracket has been fixed in place, lift and hook the fire onto the
upward facing hooks. At the bottom of the back casing, is a fold out tag. Fold this down so as to expose it under the fire when it is hung in place.
Mark through the hole in the tag; remove fire from its position, drill the hole and fit rawl plug. Hang the fire back on the wall and safely secure.
Using as a Hole in the Wall.
The inset dimensions for Hole in the Wall: 100mm (Depth), 560mm (Height), and 540mm (Width) (fig.2). To prevent the fire from being pulled out
from the wall it must be secured into place. The height at which you fix the fire to the wall should be no less than 60cm from the floor to the
bottom of the fire. Remove the outer spacer frame to expose the fire inner casing. Fasten the MDF wall brackets as in fig.2 using 60mm screws
and large wall plugs. Matching wall brackets are on the back of the Fires front and it may be positioned into the hole, then up and over into place.
The fire must be positioned so that the plug socket is accessible once the fire has been installed. In the unlikely event of breakdown access must
be allowed to the rear so that the fire maybe serviced, do not seal to the wall. The mains cable must therefore be long enough to allow this. If
the removal of the plug is absolutely necessary for installation, cut off in an area within 100mm only of the plug itself. Any further may affect
your warranty. Where the inset fire is being used in an existing chimney, it is important that the chimney is blocked off to prevent airflow
problems with the fire. Where a chimney is not blocked off sufficiently, it may cause the heater to cut out and the flame effect to stop or work
inefficiently.

Electrical connections

Your appliance comes fitted with a plug that incorporates a 13A fuse. The replacement fuses must be 13A and ASTA approved. If the fuse cover is lost the plug must
not be used until a replacement cover, of the same colour, is obtained from an electrical retailer.
The appliance is fitted with a moulded plug if it is necessary cut off the plug, for any reason, it must be discarded immedia tely with the fuse removed. Under
no circumstances should any attempt be made to reuse the plug, do not insert into any 13A socket as this could cause a hazard . If the mains cable is
damaged it must be replaced by the manufacturer or an authorised technical service centre.
WARNING THIS APPLIANCE MUST BE EARTHED
As the colours of the wires in the mains lead of this appliance may not correspond with the colour markings in your plug proceed as follow s: -
The wire which is coloured green and yellow must be connected to the terminal in the plug which is marked with the letter E, or coloured green
or coloured green and yellow, or marked with the earth symbol
The wire which is coloured blue must be connected to the terminal in the plug which is marked with the letter N, or coloured black.
The wire which is coloured brown must be connected to the terminal in the plug which is marked with the letter L, or coloured red.

Fuel Effects

Unpack the fuel effect from the accessory box and arrange in a random formation on top of the fuel bed.
Areas around the fire will become hot when activated. We strongly recommend small children be kept away from having any direct
contact with the appliance by means of fitting a fireguard. This appliance is not intended for use by persons (or children) with reduced
Flamerite Valliant Wall Mounted Electric Fire

Installation of fire

fig.1
The wires in the mains lead are coloured in accordance with the following code.
Green and yellow:
Blue:
Red:
Operating The Fire
Page 1 of 2
IMPORTANT
EARTH
NEUTRAL
LIVE
fig.2
