Flamerite Fires Sonata-2 Instructions

Remove the fire from the packing, checking that neither the heater nor the power cable has been damaged during transport. Do not operate the
heater if damaged. The accessories are found in a box that is packed at the side of the fire. Your fire is guaranteed for one year from the date of
purchase. In the unlikely event of a breakdown you have access to our customer services team, simply call 01543 251122 during office hours, 9am
– 5pm or e-mail on info@flameritefires.com
Where a chimney is not blocked off completely it will cause the heater to cut out during use.
Your fire has been designed for use as part of a fireplace mantel and surround suite. A minimum depth of up to 140mm may be required. The
dimensions of the aperture in the decorative back panel into which the fire fits are, height maximum 595mm and minimum 560mm and width
maximum 440mm and minimum 405mm. The fire must be positioned so that the plug socket is accessible once the fire has been installed. In the
unlikely event of breakdown access must be allowed to the rear so that the fire maybe serviced, do not seal to the wall. The mains cable must
therefore be long enough to allow this. If the removal of the plug is absolutely necessary for installation, cut off in an area within 100mm only of
the plug itself. Any further may affect your warranty. Where the inset fire is being used in an existing chimney, it is important that the chimney is
blocked off to prevent airflow problems with the fire. Where a chimney is not blocked off sufficiently, it may cause the heater to cut out and the
flame effect to stop or work inefficiently.

Electrical connections

Your appliance comes fitted with a plug that incorporates a 13A fuse. The replacement fuses must be 13A and ASTA approved. If the fuse cover is
lost the plug must not be used until a replacement cover, of the same colour, is obtained from an electrical retailer.
The appliance is fitted with a moulded plug if it is necessary cut off the plug, for any reason, it must be discarded immediately with the fuse
removed. Under no circumstances should any attempt be made to reuse the plug, do not insert into any 13A socket as this could cause a
hazard. If the mains cable is damaged it must be replaced by the manufacturer or an authorised technical service centre.
WARNING THIS APPLIANCE MUST BE EARTHED
As the colours of the wires in the mains lead of this appliance may not correspond with the colour markings in your plug proceed as follows: -
The wire which is coloured green and yellow must be connected to the terminal in the plug which is marked with the letter E, or
coloured green or coloured green and yellow, or marked with the earth symbol
The wire which is coloured blue must be connected to the terminal in the plug which is marked with the letter N, or coloured
black.
The wire which is coloured brown must be connected to the terminal in the plug which is marked with the letter L, or coloured
red.

Fuel Effects

Once the firep has been installed in the correct position unpack the fuel effect from the accessory box and arranged in a random formation
on top of the fuel bed.

Controls (Remote)

The main on/off switch is marked with I/O and will need to be switched to I to operate the fire. In this position you will be
unable to operate the fire further unless the
To operate the flame effect (and further functions) simply press and release the
To set the flame effect to your desired brightness press then release + or - buttons marked either side of the
For 750W of heat, press then release the button marked
button marked I/II. You may alternate from 750W to 1.5KW by pressing
then release the button marked
To turn the flame effect off and deactivate the heater and dimmer functions press then release the button marked
To turn the fire off completely the main on/off switch must be switch back to O.
Sonata-2 Instructions

Installation of Fire

The wires in the mains lead are coloured in accordance with the following code.
Green and yellow:
Blue:
Red:

Operating the fire

button on the remote or keypad is pressed first.
O/I. The heater will always start on the lower setting
IMPORTANT
EARTH
NEUTRAL
LIVE
button on the remote or keypad.
O/I. To increase the temperature to 1.5KW press then release
I/II at anytime. To turn the heater off, press
Page 1 of 2
icon.
.
