Pro-Form 850 User Manual page 7

3. Attach the Rear Stabilizer (7) to the Frame (2)
with two M10 x 127mm Button Screws (83).
Next, hold the handle on the Frame (2), press
the Latch Button (68), and lower the Frame until
the Rear Stabilizer (7) is resting on the floor.
4. Hold a Hub Cover (75) and a Crank Arm (36)
against the left Crank Hub (38).
Align the holes in the Hub Cover (75) and the
Crank Arm (36) with the unused holes in the left
Crank Hub (38).
Insert four Hub Screws (87) into the Hub Cover
(75) and the Crank Arm (36), and finger tighten
the Hub Screws into the left Crank Hub (38).
Tighten one of the Hub Screws (87), and then
tighten the Hub Screw across from the first Hub
Screw. Then, tighten the remaining two Hub
Screws.
Repeat this step on the right side of the ellipti-
cal; make sure that the Crank Arms (36) are
oriented so that the Crank Bushing Sleeves
(43) are oriented as shown.
Note: There are no Pulley Screws (98) on the
right side.
3
Handle
4
98
38
36
75
87
87
43
7
83
7
2
68
43
36
