  • Page 1 Model No. PFEL77807.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? As a manufacturer, we are commit- ted to providing complete customer satisfaction. If you have questions, or if parts are damaged or missing, PLEASE DO NOT CONTACT THE STORE;...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. .2 IMPORTANT PRECAUTIONS .
  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your elliptical exerciser before using your elliptical exerciser. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.
  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary PROFORM tacting us. The model number and the location of the ® 850 elliptical exerciser. The 850 elliptical exerciser serial number decal are shown on the front cover of provides an impressive array of features designed to this manual.
  • Page 5: Assembly

    ASSEMBLY To hire an authorized service technician to assemble the elliptical exerciser, call 1-800-445-2480. Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included hex keys and your own Phillips screwdriver , adjustable wrench...
  • Page 6 To make assembly easier, read the information on page 5 before you begin assembling the elliptical exerciser. Remove the two M10 x 120mm Patch Screws (58) and the shipping bracket (not shown) attached to the front of the Frame (1). Discard the shipping bracket.
  • Page 7 3. Identify the Upright (3) and orient it as shown. Have a second person holds the Upright near Avoid pinching the the top of the Frame (1). Locate the wire tie Wire Harness (46) (see the inset drawing) in the Upright. Tie the during this step lower end of the wire tie to the Wire Harness (46).
  • Page 8 5. Identify and orient the Ramp (2) as shown. Tip: Remove the Ramp Cover (not shown) from the Ramp and set it aside until step 9. Attach the Ramp to the Frame (1) with four M10 x 27mm Patch Screws (64). Tip: To prevent squeaking, do not overtighten the Patch Screws.
  • Page 9 7. Insert the axle of a Roller (27) through the right Link Arm (25); make sure that the Roller is on the inner side of the Link Arm. Attach the Roller with an M10 x 15mm Patch Screw (71) and an M10 x 22mm x 1.5mm Washer (63). Tip: Use a wrench to hold the axle of the Roller firmly in place while you tighten the Patch Screw into the axle.
  • Page 10 9. Attach the Ramp Cover (7) to the Ramp (2) with six #8 x 1/2” Screws (79). 10. Remove the shipping bracket (not shown) inserted into the underside of the Frame (1). Discard the shipping bracket. While a second person tips the Frame (1) for- ward, tighten a Foot (9) into the underside of the Frame.
  • Page 11 11. While a second person tips the elliptical exercis- er forward, attach the Rear Ramp Cover (17) to the Ramp (2) with four #8 x 2" Screws (68). 12. Make sure that all parts of the elliptical exerciser are properly tightened. Note: Some hardware may be left over after assembly is completed.
  • Page 12: How To Use The Elliptical Exerciser

    HOW TO USE THE ELLIPTICAL EXERCISER HOW TO PLUG IN THE POWER SUPPLY HOW TO EXERCISE ON THE ELLIPTICAL EXERCISER Plug one end of the included power supply into the jack on the front of the elliptical exerciser. Plug the To mount the elliptical exerciser, hold the handlebars other end of the power supply into an appropriate out- and step onto the pedal that is in the lower position.
  • Page 13 CONSOLE DIAGRAM FEATURES OF THE CONSOLE Destroyer™ game during your workouts—the harder you exercise, the greater the advantage you will have! The revolutionary console offers an array of features The console keeps track of the four highest scores for designed to make your workouts more effective and each game—compete with other users or try to top enjoyable.
  • Page 14 HOW TO USE THE MANUAL MODE Note: If there is a sheet of clear plastic on the face of the console, remove the plastic. 1. Begin pedaling or press any button on the con- sole to turn on the console. A moment after you begin pedaling or press a but- ton, the display will light.
  • Page 15 5. Measure your heart rate if desired. onds. Note: If you continue to hold the handgrip pulse sensor, the display will show your heart rate If there are sheets for up to 30 seconds. of clear plastic on the metal con- If the display does not show your heart rate, make tacts on the hand- sure that your hands are positioned as described.
  • Page 16 HOW TO USE A TRAINER WORKOUT As you exercise, you will be prompt- 1. Begin pedaling or press any button on the con- ed to keep your sole to turn on the console. pedaling pace near the target rpm set- A moment after you begin pedaling or press a but- ting for the current ton, the display will light.
  • Page 17 HOW TO PLAY THE FAT BLOCKER GAME Your goal is to maneuver the Complete Row The Fat Blocker game requires quick thinking and fast blocks so that they reflexes. In addition to the console buttons, you will form a complete use the four-button game controllers on the handlebar row of black to play the game.
  • Page 18 HOW TO PLAY THE CALORIE DESTROYER GAME Between the drones and the laser blaster are five shields. You can hide the laser blaster below a The Calorie Destroyer game is a fast-paced game that shield if desired. However, each time a shield is hit pits you against a squadron of laser-firing drones.
  • Page 19: Maintenance And Troubleshooting

    HOW TO USE THE STEREO SOUND SYSTEM your iPod, MP3 player, or CD player. Make sure that the audio cable is fully plugged in. This product has been designed specifically to work with iPod and has been certified by the developer to To use the iFit ®...
  • Page 20: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning time. During the first few minutes of exercise, your this or any exercise program, consult your body uses carbohydrate calories for energy.
  • Page 21: Part List

    PART LIST—Model No. PFEL77807.0 R1107A Key No. Qty. Description Key No. Qty. Description Frame Link Arm Endcap Ramp Wire Harness Upright Power Harness Console Left Pedal Bracket Rear Shield Cover Stabilizer Upright Cover Stabilizer Endcap Ramp Cover M6 x 9mm Patch Screw Wheel M8 x 50mm Hex Bolt Foot...
  • Page 22: Exploded Drawing

    EXPLODED DRAWING A—Model No. PFEL77807.0 R1107A...
  • Page 23 EXPLODED DRAWING B—Model No. PFEL77807.0 R1107A...
  • Page 24: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
