- Page 1 Diagnostix ADST A TION Modular Diagnostic System...
- Page 2 Adstation comes complete with assembled Wallboard, mounting mollies and wood screws for easy installa- tion. ® 1. Choose a location for the ADC Diagnostix Adstation near the examination table and an electrical outlet. See Figure 1. 2. We recommend a height of 67 in. (170 cm) from the floor, to the top edge of your Wallboard.
- Page 3 Reposition the wallboard over the anchors and secure the wall- board by inserting screws and tightening. Be sure to double check level before installing all the mounting screws. Use the en- closed screw caps on top of each screw once they are securely tightened to finish.
- Page 4 Using the enclosed module connection cable, plug one side of the connector into the socket on the transformer module located on the right side transformer panel behind sliding door. Plug the opposite end into the extension module contact, located on the left side panel sliding door. As you add additional modules, each needs to be connected in similar fashion using the additional connection cables for each module.
- Page 5 Small Wallboard 23.25” (59.05 cm) 13.625” 34.62 cm 67” 170 cm (Figure 2) Large Wallboard 32.75” (83.19cm) 13.625” (34.62cm) 67” 170 cm (Figure 3) (Figure 4) IB p/n: 93-5600-00 rev 1...
