ADC Diagnostix 2100 Directions For Use Manual

Fingertip pulse oximeter
Hide thumbs Also See for Diagnostix 2100:

Advertisement

Table of Contents

®
ADC
Diagnostix
TM
2100
Fingertip Pulse Oximeter
Directions
for Use
1

Advertisement

Table of Contents
loading

Related Manuals for ADC Diagnostix 2100

Summary of Contents for ADC Diagnostix 2100

  • Page 1 ® Diagnostix 2100 Fingertip Pulse Oximeter Directions for Use...

  • Page 2: Device Description And Intended Use

    ® Fingertip Pulse Oximeter Thank you for purchasing an ADC Diagnostix Brand Fingertip Pulse Oximeter. We’re proud of the care and quality that goes into the manufacture of every product that bears our name. With proper care and maintenance your Diagnostix Fingertip Pulse Oximeter will provide many years of dependable service.

  • Page 3: Symbol Definitions

    Contraindications: • The patient suffers from significant levels of dysfunctional hemoglobins (such as carboxyhemoglobin or methemoglobin). • Intravascular dyes such as indocyanine green or methylene blue have been injected into the patient. • Used in the presence of high ambient light (ie, direct sunlight). Shield the sensor area with a surgical towel if necessary.

  • Page 4: General Warnings

    General Warnings A warning statement in this manual identifies a condition or practice which, if not corrected or discontinued immediately, could lead to patient injury, illness, or death. WARNING: Before use, carefully read the manual. WARNING: Do not use the pulse oximeter in an MRI or CT environment. WARNING: The operation of Pulse Oximeter may be affected by the use of an electrosurgical unit (ESU).

  • Page 5: Battery Installation

    Brief Description of Front Panel Pulse Rate Signal Intensity Bar Graph Pulse Rate Power Switch Low Power Waveform Indicator Included Pulse Oximeter Accessories • One (1) lanyard • Two (2) AAA batteries • One (1) user manual • One(1) rubberized bumper Battery Installation 1.

  • Page 6: Operating Instructions

    Operating Instructions 1. Be sure to insert two AAA batteries before attempting to operate. 2. Clean inside surface of oximeter and patient’s finger with isopropyl alcohol before use. 3. Squeeze the end opposite the power switch between the thumb and forefinger in order to open the device.
  • Page 7 Changing Oximeter Display Mode There are six different display modes. The display modes alter the orientation of the display to facilitate reading by the observer. Horizontal modes display the pulse wave form along with SPO2 and pulse rate while vertical modes display a pulse rate bar graph along with the SPO2 and pulse rate readings.

  • Page 8: Changing The Display Brightness

    Alarm On models equipped with an alarm, the alarm condition will appear when: SPO2 < 90% / PR <60 or >100bpm If the unit is in display mode 1 (silent mode), the parameter (SPO or PR) flashes and an audible beep is heard if it exceeds the alarm condition. If the unit is in display modes 2-6 (audible mode), the unit will beep during measurement and will signal and alarm condition with both visual and audible alerts.

  • Page 9: Cleaning The Pulse Oximeter

    Cleaning the Pulse Oximeter Clean the rubber touching the finger inside of the Oximeter with a soft dampened cloth with 70% isopropyl alcohol, and clean the test finger using alcohol before and after each test. Note: Do not pour or spray any liquids onto the Oximeter, and do not allow any liquids to enter any openings in the device.
  • Page 10 Guidance and Manufacturer’s Declaration Electromagnetic Emissions Guidance and Manufacturer’ s declaration - electromagnetic environment specified below. The customer or the user of the PULSE OXIMETER should assure that it is used in such an environment. Compliance Level Emission Test Electronic Environment Guidance RF Emissions CISPR11 Group 1 The PULSE OXIMETER uses very low RF energy only and...
  • Page 11 Guidance and Manufacturer’s Declaration - Electromagnetic Immunity For all Equipment and Systems that are not Life-Supporting Guidance and Manufacturer’ s declaration - electromagnetic environment specified below. The customer or the user of the PULSE OXIMETER should assure that it is used in such an environment. IEC 60601 Test Compliance Immunity Test...

  • Page 12: Technical Specifications

    Technical Specifications Display Type: OLED Display SPO2 display range: 0-100% PR Display Range: 30-235 BPM PR Display Mode: Bargraph Data Update Time: < 15 s LED Wavelengths 660nm Red: 940nm Infrared: Measurement range: 70-99% - 100% ±3%; s 70% no definition SPO2: 30-235 BPM, ±2 bpm during the pulse rate range Pulse Rate:...

  • Page 13: Warranty

    2. Your Pulse Oximeter is warranted for two (2) years from date of purchase (all parts). What is Covered: Replacement of parts, and labor. What is Not Covered: Transportation charges to and from ADC . Damages caused by abuse, ®...
  • Page 14 1-800-ADC-2670 OR VISIT www.adctoday.com/feedback This manual is available online in a variety of languages, follow the links for language options. www.adctoday.com/care Dist. by: ADC ® Beijing Choice 55 Commerce Drive Electronic Technology Co., Ltd. Hauppauge, NY 11788 Room 4104, No. A12 Yuquan Road Haidian District, 100143 Inspected in the U.S.A.
