Pin - Outs; Null Modem Cable; Pc-At Serial Cable - 3Com SuperStack II 3C16987 User Manual

B

Null Modem Cable

PC-AT Serial Cable

P -
IN OUTS
9-pin to RS-232 25-pin
Switch 3300 SM
Cable connector: 9-pin female
Screen Shell
TxD 3
RxD 2
Ground 5
RTS 7
8
CTS
DSR 6
DCD 1
DTR 4
9-pin to 9-pin
Switch 3300 SM
Cable connector: 9-pin female
Screen Shell
DTR 4
TxD 3
RxD 2
CTS 8
5
Ground
DSR 6
RTS 7
DCD 1
PC/Terminal
Cable connector: 25-pin male/female
1 Screen
3 RxD
2 TxD
7 Ground
4 RTS
20 DTR
5 CTS
6 DSR
8 DCD
PC-AT Serial Port
Cable connector: 9-pin female
Shell Screen
DCD
1
2 RxD
3 TxD
4 DTR
5
Ground
6 DSR
7 RTS
8 CTS
only required if screen
always required
required for handshake
only required if screen
always required
required for handshake
always required
required for handshake
