Switch 3300 SM as a
Desktop Switch
The example in
Figure 5
within a stack, for a group of users that require dedicated 10Mbps or
100Mbps connections to the desktop. The 3300 SM Switches provide a
Gigabit Ethernet connection to a SuperStack II Switch 9300 in the
basement and to a local server.
Figure 5 Using the Switch in a desktop environment
1000Mbps
Network Configuration Examples
shows how a Switch 3300 SM can be used,
Switch 3300:
Endstations on switched 10Mbps
Switch 9300
SM
SM
Local server on a switched
XM
1000Mbps connection
MM
or 100Mbps connections
19
