Switch 3300 SM —
Rear View Detail

Power Socket

Redundant Power System Socket

Unit Information
Label
Power Socket
Redundant Power
System Socket
Figure 2 Switch 3300 SM — rear view

Unit Information Label

Switch 3300 SM 24 Port
3C16987
MAC Addr: XXXXXXXXXX
Serial XXXXXXXXXXXX
This label shows the following:
The 3Com product name of the Switch
The 3Com 3C number of the Switch
The unique MAC address (Ethernet address) of the Switch
The serial number of the Switch
You may need this information for fault reporting purposes.
The Switch automatically adjusts its power setting to any supply voltage
in the range 90–240V A.C.
To protect against internal power supply failure, you can use this socket
to connect a SuperStack II Advanced Redundant Power System (ARPS) to
the Switch. See "Connecting a Redundant Power System"
Switch 3300 SM — Rear View Detail
Console
(max) 19200,8,1,N
Console Port
15
Matrix Port
Matrix Port
on page 29.
