Switch 3300 SM —
Front View Detail
1x
13x
10BASE-T / 100BASE-TX Ports
10BASE-T/
100BASE-TX Ports
1000BASE-SX Port
LEDs
Figure 1 Switch 3300 SM — front view
6x
7x
18x 19x
The Switch has 24 auto-negotiating 10BASE-T/100BASE-TX ports
configured as MDIX (cross-over). These ports can be set to 10BASE-T half
duplex, 10BASE-T full duplex, 100BASE-TX half duplex, 100BASE-TX full
duplex, or they can automatically detect the speed and duplex mode of a
link and provide the appropriate connection. The maximum segment
length is 100m (328ft) over Category 5 twisted pair cable.
As these ports are configured as MDIX (cross-over), you need to use a
cross-over cable to connect to devices whose ports are MDIX-only. See
"Choosing the Correct Cables"
The Switch has a Gigabit Ethernet Port that provides a 1000Mbps
connection to another Gigabit Ethernet device. This port uses 62.5 m or
50 m multimode fiber optic cable with MT-RJ duplex connectors.
Table 3
(overleaf) lists the LEDs visible on the front of the Switch, and
their states according to color. For information on using the LEDs for
problem solving, see
Switch 3300 SM — Front View Detail
10BASE-T / 100BASE-TX
1000BASE-SX
12x
green
= enabled, link OK
flashing green
= disabled, link OK
1
2
3
4
5
6
7
8
9
10
11
12
Packet
1
2
3
4
5
6
7
8
9
10
11
12
Status
13
14
15
16
17
18
19
20
21
22
23
24
Packet
13
14
15
16
17
18
19
20
21
22
23
24
Status
24x
Port Status LEDs
1000BASE-SX Port
on
page 30
"Solving Problems Indicated by LEDs"
Unit
1
2
3
4
5
6
Power/Self Test
®
SuperStack II
7
8
Switch 3300 SM
Power / Self Test LED
Unit LED
for more information.
on
page
13
31.
