Switch 3300 SM as a
Collapsed Backbone
Switch
S
3300 SM
WITCH
The example in
Figure 4
backbone for both shared and switched network segments.
Figure 4 Using the Switch as a collapsed backbone
Endstations on
shared 10Mbps
and 100Mbps
connections
Dual Speed Hub 500
Endstations on
shared 10Mbps
and 100Mbps
connections
Dual Speed Hub 500
Endstations on switched
10Mbps connections
shows how a Switch 3300 SM stack can act as a
100Mbps
Switch 3300 SM stack
Endstations on
switched 10Mbps
connections
Switch 1100
Endstations on
switched 10Mbps
connections
Switch 1100
Servers on dedicated
1000Mbps connections
