Table below includes explanations of the Device settings tab:
Setting
Preview images
New patient folder
Erase image memory
Edit patient list
Patient information
Display brightness
Icons
Sounds
Keyboard backlight
Select language
USB write protection
Video file format
Image transfer
method
Restore factory
Setting
SD card firmware
update mode
Date
Time
Camera SW version
Start query
Wireless
Wireless info
Preview images
Image preview is opened by selecting "Preview files" with a middle key. Images are browsed by using
arrow keys. Display gives information about usage of the image preview.
Image can be zoomed while previewing by pressing middle key. Move around the image by pressing arrow
keys. Change between the four zoom levels by pressing middle key.
Patient ID information can be edited in image browser.
Values (default bolded)
Ok
Ok
Ok
Ok
On/Off
Low-Med-High
On/Off
On/Off
On/Off
ENG-FIN-FRA-GER-ITA-
JPN-POR-SPA-ZHO
On/Off
MPEG4/MPEG1
UMS/WIA
Ok
Ok
DD-MM-YYYY
HH:MM
Show camera SW version
Era./Fol./None
On/Off
Ok
Purpose
To preview the images on camera press middle button.
To create a new patient folder press middle button. New
patient folder can also be created in live view by long
pressing the middle key.
Select middle button to erase images and videos from
camera SD card.
Press middle key to edit patient list
Enable or disable patient information linking
Use left and right arrow keys to adjust display brightness
Show graphical icons when imaging.
When enabled, sound is played during image capture
When enabled, keyboard illumination is on
Use left and right arrow keys to select camera language
When enabled, writing to SD card is not allowed when
device is in cradle. This feature helps prevent any viruses
getting from PC to the camera. Note that if device contains
WLAN card, during its setup or updating of its firmware,
USB write protection need to be temporarily set off.
Use left and right arrow keys to select video file format
Use WIA for automatic and UMS for end-user activated
image transfer. UMS can be used in most cases.
To restore all settings menus to factory defaults. Activate
using the middle key. Note that also Wireless password is
restored to default.
To start SD card firmware update mode, press middle
button.
Use up and down arrow keys to set date.
Use up and down arrow keys to set time.
Browse version information with left and right arrow key
Choose the startup query between memory erase, new
patient folder or no query at all.
Enable or disable wireless connection
To view 'WLAN SSID' and 'WLAN Password', press middle
button.
