7.3. Basic use – starting up, shutting down and taking an image
Device is powered on by pressing left soft key.
It is possible to capture both still images and video. Image capture mode is changed from camera menu
(optics specific tab) that opens by pressing right soft key for 1s.
Still image is captured using the dual action shutter to the second position. Video is captured by keeping
the dual action shutter pressed down in the second position.
Taken image will stay on display until it is cleared by pressing right or left soft key. Image can be zoomed
in instant preview by pressing middle key. There are four zoom levels. Pressing middle key activates the
next level. Move around the image by using arrow keys.
To transfer images to a PC via USB connection, place device to the cradle. The image transfer and charging
is indicated with green and blue LED-lights and text on LCD-screen. In case the WLAN connection is active
images are transferred to the PC automatically.
NOTE:
If images are corrupted or not transferred to the PC, the original images are saved to the
memory card. Please try again to transfer images to the PC via USB.
Smartscope verifies if image data is erased either when device is powered on from power off mode or
power save mode or when device is removed from the cradle. It is recommended that image data storage
is always erased with a new patient.
Device is powered off by keeping left soft key pressed down over 1 second.
NOTE:
When device is powered on, powered off or goes to standby mode the camera focus motor
may make a sound. This sound is normal and is not a sign of any damage or problem.
7.3.1.

Image quality analysis

After capturing an image, the image quality analysis is performed if image quality analysis is enabled from
optics menu. The results of image quality analysis are shown in instant review with the image. Letter B
represents the brightness of the image. If the brightness of the image is good, the indicator is shown as
green. The indicator is shown as yellow, if the image is little bit over or under exposed. If the image is
severely over or under exposed the indicator is shown as red.
Letter R represents reflections and shadowing. If the image
has no reflections or shadowing, the indicator is shown as
green. The indicator is shown as yellow, if the image has small
reflections or shadows. If the image has large reflections or
shadows, the light is red.
Letter S represents sharpness. If the image is sharp, the
sharpness value is green. The indicator is yellow, if the image
is not sharp enough. For un-sharp image, the indicator light is
shown as red.
