Attention:
Carefully read through the instal-
lation and operating instructions
and safety information before
installing and putting the unit into
service.
These instructions must always
be issued to the owner/user.
Installation and
operating instructions
JUDO FIMAT
Backwash protective filter
Model JFXL-M 1½" - 2"
Model JFXL-T 1½" - 2"
Model JFXL-TP 1½" - 2"
Valid for: EU countries and Switzerland
JFXL-M 1½" - 2"
JFXL-TP 1½" - 2"
Advertisement
Table of Contents
Related Manuals for Judo FIMAT JFXL-M 1 1/2
Summary of Contents for Judo FIMAT JFXL-M 1 1/2
- Page 1 Installation and operating instructions JUDO FIMAT Backwash protective filter Model JFXL-M 1½" - 2" Model JFXL-T 1½" - 2" Model JFXL-TP 1½" - 2" Valid for: EU countries and Switzerland Attention: Carefully read through the instal- lation and operating instructions...
- Page 2 See back page. Trademarks: Trademarks used in this document are protected and registered trademarks of the respective holder. © JUDO Wasseraufbereitung GmbH 71364 Winnenden Germany All rights reserved. Reprints – even of extracts – is only permitted with special approval.
- Page 3 JUDO FIMAT...
-
Page 4: Table Of Contents
24 safe and proper work must also be 10. Spare parts........25 observed. 10.1 Spare parts list ......26 11. Customer service ......28 Therefore, this instruction manual must always be read by the fitter and responsible JUDO FIMAT... -
Page 5: Symbols Used
– Direction of flow (see fig. 1) 1 m³/h = 3.67 gpm (Imp.gal.) – Rating plate 1½" DN 40 – Cleaning information 2" DN 50 must always be observed and kept in a fully legible condition. Fig. 1: Built-in rotary flange JUDO FIMAT... -
Page 6: Intended Use
If the filter is not The use of the device in accordance with the backwashed regularly a pressure loss can customer’s specifications includes result and this can impair the filter function. observance of the operating instructions. JUDO FIMAT... -
Page 7: Notes On Special Dangers
In addition this may also result in short circuits if these electrical devices / JUDO FIMAT... -
Page 8: Product Information
Plastics fulfil the KTW-Guideline of the UBA (Umwelt- bundesamt / Federal Environmental Agency) and the DVGW working sheet W 270, and metallic materials fulfil the requirements of DIN 50930-6 (Impact on the drinking water quality). JUDO FIMAT... - Page 9 4.1.1 Transport / Storage – A socket outlet with earthing contact, for the automatic filter's power supply unit, The JUDO FIMAT backwash protective filter is required above the backwash protec- has to be guarded against great shock load. tive filter with a continuous power supply at a maximum distance of 60 inch 4.1.2 Requirements for the place of...
- Page 10 (see fig. 3 II). – Tighten the four flange screws. Select the torque (approx. 4 Nm) so that the gasket closes and the filter is not damaged or strained! ATTENTION (see chapter “Safety information dangers due to non-compliance”) JUDO FIMAT...
-
Page 11: Discharging The Backwashing Water
Otherwise it is possible for the bucket to overflow. Therefore the bucket must be Example: JFXL-M adequately dimensioned and the back- Fig. 5: Backwashing water discharge options washing should be carried out quickly. JUDO FIMAT... -
Page 12: Operation
Red flashing light: The backwash protec- tive filter is not ready for use (see chapter “Fault”). Manual release Push the manual pushbutton. Triggers backwashing. Indication of maintenance All three control lamps flash at the same time (see chapter “Warranty and services”). JUDO FIMAT... -
Page 13: Differential Pressure Control
Ensure that the wastewater con- nection functions before plugging the power supply unit into the socket. – The backwash protective filter is ready for operation after backwashing. Manual start of backwashing proce- dure: Push manual button. The backwash time is set back. JUDO FIMAT... -
Page 14: Function
1) Depending on the amount of dirt arising Function JUDO FIMAT backwash protective filter with time control JFXL-T: The JUDO FIMAT backwash protective filter With respect to JFXL-T, the automatic back- removes all coarse and fine-grained impuri- washing procedure has been set for one ties. -
Page 15: Backwashing
As a result a filter function is not any longer ensured. In addition, larger quan- tities of dirt can cause mechanical impair- ment concerning the backwashing function. JUDO FIMAT... -
Page 16: Potential-Free Message
The relay can be connected as a break contact or as a make contact. If the filter power supply unit is plugged in the relay changes 1 its switched condition. If a fault message occurs the relay switches to “Power-off or fault”-state. JUDO FIMAT... -
Page 17: Integration Of The Filter In The Building Control Systems
The imprinted test marks are only valid if original spare parts are used. In addition, the external input of the filter control can be used concerning the remote control (flush start-up, flush-blocking). JUDO FIMAT... -
Page 18: Servicing / Repair
Leaking water can cause major material- damages to the building. In addition, people near the filter can be injured by blistering filter parts. – When re-commissioning the filter, same course of action as applied to the new filter. JUDO FIMAT... -
Page 19: Fault
– Remove mains plug from the socket! Filter cover becomes Filter hood has been – Close ball valves! turbid. exposed to high tempera- tures or solvents. – Inform the fitter or nearest Hairline cracks on the customer service centre! filter hood. JUDO FIMAT... -
Page 20: Maintenance
DIN EN 13441-1 specifies that backwashing dangers due to non-compliance”) must take place at least every six months. Always observe the chapter “Intended use”! However, JUDO recommends to carry out backwashing every two months! Cleaning Regular inspection and routine servicing are... -
Page 21: Data Sheet
Data sheet Data sheet Type JUDO FIMAT Backwash protective filter Abbreviated name: JFXL Models Time Diffential pressure Model Manual model Order no. control control JFXL-M 1½" • 8010085 JFXL-M 2" • 8010089 JFXL-T 1½" • 8020099 JFXL-T 2" • 8020100 JFXL-TP 1½"... -
Page 22: Technical Data
6.5 - 20 gpm (Imp.gal.) 1½" - 2" 0.5 - 1.5 l/s 1) The backwashing volumetric flow given ap- plies to 29 - 44 psi (200 - 300 kPa) mains pressure and for a completely opened flush- ing water valve. JUDO FIMAT... -
Page 23: Installation Dimensions
(11.2) (6.6) (5.4) All dimensions in mm (inch) (see fig. 9) Extent of supply – Pre-installed backwash protective filter – Built-in rotary flange JQE 1½" or 2" with bayonet fixture and screw connection – Installation and operating instructions JUDO FIMAT... -
Page 24: Connecting Diagram For Filter Control With Potential-Free Relays
HE contac- tor yellow (bottom) Potential- 24 VAC brown free input pink yellow green Buzzer blue white grey Potential-free relay 2 flushing message Potential-free relay 1 faults message Fig. 10: Connecting diagram for filter control with potential-free relays JUDO FIMAT... -
Page 25: Spare Parts
Spare parts 10. Spare parts JFXL-T, -TP JFXL-M JFXL-TP JFXL-M, -T JUDO FIMAT... -
Page 26: Spare Parts List
HE contactor red HE contactor yellow 11A Ring for assemby clip 11B Assembly clip Push key Manual key button Hexagonal nut M8 Cable connection M8 Grommet Sheet metal screw 3.5x9.5 Handwheel lid Countersunk screw M5x12 Disc A 6.4 JUDO FIMAT... - Page 27 Cylinder head screw M8x35 1650107 1) AU = Accounting unit (Items without AU are only available in a set.) 2) Accounting unit not yet defined at press time. Replacement interval: *** = 3 years, **** = 4 years JUDO FIMAT...
-
Page 28: Customer Service
Postfach 380 • D-71351 Winnenden Tel. +49 (0)7195 / 692-0 e-mail: info@judo.eu • judo.eu JUDO Wasseraufbereitung GmbH • Niederlassung Österreich Zur Schleuse 5 • A-2000 Stockerau Tel. +43 (0)22 66 / 6 40 78 • Fax +43 (0)22 66 / 6 40 79 e-mail: info@judo-online.at •...
