Attention:
Carefully read through the instal-
lation and operating instructions
and safety information before
installing and putting the unit into
service.
These must always be issued to
the owner/user.
Prolongated guarantee
period if a maintenance
contract has been con-
cluded!
Installation and
Operating Instructions
JUDO PROFI-PLUS
Backwash Protective Filter ¾" – 2"
Valid for: EU countries and Switzerland
Language: English
+
Fig.: JPF
¾" – 1¼"
+
¾
– 1¼
JPF
"
"
+
Fig: JPF
1½" – 2"
+ 1", 1¼"
JPF
Advertisement
Table of Contents
Related Manuals for Judo PROFI-PLUS
Summary of Contents for Judo PROFI-PLUS
- Page 1 Installation and Operating Instructions JUDO PROFI-PLUS Backwash Protective Filter ¾" – 2" Valid for: EU countries and Switzerland Language: English Attention: Carefully read through the instal- lation and operating instructions and safety information before installing and putting the unit into service.
- Page 2 See back page. D-71364 Winnenden Trademarks: Trademarks used in this document are protected and registered trademarks of the respective hold- © JUDO Wasseraufbereitung GmbH D-71351 Winnenden All rights reserved. Reprints – even of extracts – is only permitted with special approval.
- Page 3 JUDO PROFI-PLUS...
-
Page 4: Table Of Contents
1½" – 2" ......26 and proper work must also be observed. 11. Customer Service......28 Therefore, this instruction manual must al- Enclosure: Consultation Voucher ways be read by the fitter and responsible skilled personnel/owner or operator before JUDO PROFI-PLUS... -
Page 5: Symbols Used
– Direction of flow (see Fig.1) 1" DN 25 – Rating plate 1¼" DN 32 – Cleaning information 1½" DN 40 must always be observed and kept in a fully 2" DN 50 legible condition. Fig. 1: Built-in rotary flange JUDO PROFI-PLUS... -
Page 6: Intended Use
The op- erator is responsible for these risks. The use of the device in accordance with the customer’s specifications includes the ob- servance of the operating instructions. JUDO PROFI-PLUS... -
Page 7: Water Pressure
(IP44). 1 = Pressure reducer Fig. 2: Pressure reducer upstream of the unit The installation of a pressure re- duction valve is recommended for water pressures between 5 bar and 10 bar. JUDO PROFI-PLUS... -
Page 8: Product Information
DIN 19632 (“Me- chanical filters in drinking water installa- tions”). All materials are hygienically and physiologically safe. Plastics (KTW recom- mendations) and metallic materials fulfil the requirements of the BgVV (German Federal Institute for Consumer Health Protection and Veterinary Medicine). JUDO PROFI-PLUS... -
Page 9: Installation
– The unit can be installed in all standard drinking water pipes. – It is not permitted to install the filter upst- ream of the water meter! The shipping carton can be slipped over the built-in filter to prevent damage, for instance at construc- tion sites. JUDO PROFI-PLUS... - Page 10 This can re- sult in major water damage. In this case, people close to the filter are ex- posed to a health risk due to the large quan- tities of water. JUDO PROFI-PLUS...
-
Page 11: Discharging The Backwashing Water
– When the bucket is half-filled the back- washing process must be stopped. Oth- erwise it is possible for the bucket to overflow. Therefore the bucket must be adequately dimensioned and the back- washing should be carried out quickly. JUDO PROFI-PLUS... - Page 12 4.2.1 Backwashing water discharge options ¾" – 1¼" 1½" – 2" > 200 mm > 200 mm min.10 l min.15 l > 40 mm > 20 mm > 20 mm > 40 mm Fig. 7: Backwashing water discharge options JUDO PROFI-PLUS...
-
Page 13: Operation
• Insert the two included batteries in the battery compartment. Use 1.5 V Micro batteries. • Replace the handwheel lid. Abb. 8: Funktional description • You can test the functionality by press- ing the -key in the lid of the hand- RESET wheel. JUDO PROFI-PLUS... -
Page 14: Backwashing
During this step, the suction nozzle does not 12 Fine filter only clean the sieve cloth in the fine filter a Water Inlet (12) but also the transparent filter bell (6) us- b Filtered water ing a rubber lip on its exterior side (see Fig.8). JUDO PROFI-PLUS... - Page 15 Failure to observe these instructions can result in damage to property and personal injuries. The smaller the mesh size of the screen in- sert the more frequently backwashing is re- quired! From experience, increased dirt is deposit- JUDO PROFI-PLUS...
-
Page 16: Modifications / Changes / Spare Parts
Failure to observe this can lead to an uncontrolled escape of water and therefore lead to water damage in the building. Strictly comply with the instructions given in the “Installation” and “Maintenance” chapters. JUDO PROFI-PLUS... -
Page 17: Stoppages
3 seconds. The note electronics does The battery is used up. Replace the batteries with not beep when the new ones. Return used bat- RESET key is pressed! teries to the collection cen- tres. (JPF ¾" – 1¼") JUDO PROFI-PLUS... -
Page 18: Maintenance
Such cleaners must therefore not be recycling entities. used. ATTENTION (see chapter “Safety information and dan- gers due to non-compliance”) To make sure the total interval of two- months is not exceeded, backwash the filter after replacing the batteries. JUDO PROFI-PLUS... -
Page 19: Silver Sieve
Wherever possible, the regular servicing work and supply with consumables and wearing materials, etc. should be carried out by the specialist trade or the factory’s cus- tomer service department. JUDO PROFI-PLUS... -
Page 20: Data Sheet
Data Sheet ATTENTION Type (see chapter “Safety information and dan- gers due to non-compliance”) JUDO PROFI-PLUS Filters with mesh sizes larger than 0.1 mm Backwash Protective Filter only filter correspondingly large particles Abbreviated name: JPF from the water. But backwashing must also be carried out here latest after two months to prevent germ formation. -
Page 21: Technical Data
2-3 bar mains pressure and for a completely opened flushing water valve. Weight Model Weight 4 kg ¾" 4 kg 1" 4 kg 1¼" 10 kg 1½" 10 kg 2" JUDO PROFI-PLUS... -
Page 22: Installed Dimensions ¾" - 1¼
Installed dimensions 1½" - 2" Montage: Montage: built-in rotary flange built-in rotary flange horizontal horizontal Montage: Montage: built-in rotary flange built-in rotary flange vertical vertical Abb. 10: Installed dimensions 1½" - 2" Abb. 9: Installed dimensions ¾" - 1¼" JUDO PROFI-PLUS... -
Page 23: Extent Of Supply
C = Height above pipe centre ¾" – 1¼": D = Height below pipe centre – JUDO JQR expansion quickset Order E = Depth to pipe centre no. 8250041 for the series connection of two devices, e.g. filter and water treat- ment system. -
Page 24: 10. Spare Parts
Spare Parts 10. Spare Parts 10.1 JPF " – " ¾ 1¼ JUDO PROFI-PLUS... - Page 25 1120298 Spare part set consisting of Item 13, 2010224 15, 16, 17, 19, 20, 21 1) VE = Unit of Billing Replacement interval 2 years **** = 4 years Extended warranty period if a maintenance agreement is concluded! JUDO PROFI-PLUS...
-
Page 26: Jpf + 1½" - 2
Spare Parts 10.2 JPF " " 1½ – 2 JUDO PROFI-PLUS... - Page 27 Spare part set consisting of Item 9, 10, 2010225 12, 13, 14, 16, 20 1) VE = Unit of Billing SMW = special mesh size Replacement interval 2 years **** = 4 years Extended warranty period if a maintenance agreement is concluded! JUDO PROFI-PLUS...
-
Page 28: 11. Customer Service
JUDO Wasseraufbereitung GmbH Postfach 380 • D-71351 Winnenden Tel. +49 (0)7195/6 92-0 • Fax: +49 (0)7195/6 92-188 e-mail: info@judo-online.de • www.judo-online.de JUDO France S.à.r.L 76 Rue de la Plaine des Bouchers • Technosud • F-67100 Strasbourg Tel. +33 (0)3 88 65 93 94 • Fax +33 (0)3 88 65 98 49 e-mail: info@judo.fr •...
