- Page 1 GRAUPNER/SJ GmbH 73230 KIRCHHEIM/TECK GERMANY Subject to modification! No liability for printing errors! 03/2018...
- Page 2 Thank you very much for purchasing a Graupner AMIGO V. This R/C glider model is extremely versatile. Read this manual carefully to achieve the best results with your AMIGO V and first of all to safely control your models. If you experience any trouble during operation, take the instructions to help or ask your dealer or Graupner Service Centre.
- Page 3 Intended use The AMIGO V model is an R/C glider model. If desired, the model can be equipped with motor set (not included). Read through this entire manual carefully before you attempt to assemble or use the AMIGO V. For any improper use no guarantee or liability is assumed.
- Page 4 Persons, including children, with reduced physical, sensory or mental capabilities, or lack of experience or knowledge, or not capable to use safely the AMIGO V must not use the model without supervision or instruction by a responsible person. Operation and use of radio-controlled models needs to be learnt! If you have never driven such a model, then start extra carefully and make sure to be familiar with the reactions of the model to the remote control commands.
- Page 5 General The AMIGO V model is a classical Graupner airplane model that achieves challenging flight performance. It is particularly characterized by a low airspeed and best thermal airing properties. The design was based on the version AMIGO II from 1966. The wing and tail unit adopted are exactly like the original ones. The model can start with a rubber-system, but it can optionally be flown with a motor set as a motor glider.
- Page 6 The left side of the fuselage must also be glued to the building plan. It is important to note that the left side of the fuselage has to be removed from the base again so that the back fuselage belt can be glued. GRAUPNER/SJ GmbH 73230 KIRCHHEIM/TECK GERMANY Subject to modification! No liability for printing errors! 03/2018...
- Page 7 To check the fuselage on the building plan, lay the fuselage facing to you. Fix the components with the needles or adhesive tape until the adhesive is hard. GRAUPNER/SJ GmbH 73230 KIRCHHEIM/TECK GERMANY Subject to modification! No liability for printing errors!
- Page 8 UHU Kraftkleber superstrong or instant cyano glue. The sketch shows the glued-on fuselage bottom parts (12) to (14), before the gluing of the fuselage sand again with a grinding block. GRAUPNER/SJ GmbH 73230 KIRCHHEIM/TECK GERMANY Subject to modification! No liability for printing errors! 03/2018...
- Page 9 D-D and check that the rudder is easy to move. Insert the finished rudder first into the fuselage. Check the fuselage from the front to see if it fits exactly vertically, then glue it in place. GRAUPNER/SJ GmbH 73230 KIRCHHEIM/TECK GERMANY Subject to modification! No liability for printing errors! 03/2018...
- Page 10 Lay the building plan 1 on the building surface and cover the area of the tail plane with a clear plastic film so that the components do not stick to the plan. GRAUPNER/SJ GmbH 73230 KIRCHHEIM/TECK GERMANY Subject to modification! No liability for printing errors!
- Page 11 The planking is best glued with a few cyano adhesive and then glue into the corners from below. Build the wing outer part as well as the left wing parts according to the already described scheme. GRAUPNER/SJ GmbH 73230 KIRCHHEIM/TECK GERMANY Subject to modification! No liability for printing errors! 03/2018...
- Page 12 Spannlack only to the areas in contact with the wood. In this step, the covering paper bonds with the substrate. Cover the still moist, GRAUPNER/SJ GmbH 73230 KIRCHHEIM/TECK GERMANY Subject to modification! No liability for printing errors!
- Page 13 Cover the receiver and receiver battery with foam. Note: The center of gravity of the model AMIGO V is relatively far behind, which is due to the profile of the elevator. Adjustment angle difference and control surfaces deflections The adjustment angle difference (AAD) between the setting angle of the wing + +2.5°...
-
Page 14: Parts List
Section 10x3x35 Leading edge Balsa 10x5x392 Edge profile Balsa 20x5x395 Balsa Laser part 2 Balsa Laser part 2 Balsa Laser part 2 Balsa Laser part 2 GRAUPNER/SJ GmbH 73230 KIRCHHEIM/TECK GERMANY Subject to modification! No liability for printing errors! 03/2018... - Page 15 Self-adhesive foil 515x110x0,1 Angle template Plywood Laser part 2 Surface Cardboard 20x15x0,8 Optional accessories (not included) Rubber launch start system No. 234 Motor set No. 9541.22 GRAUPNER/SJ GmbH 73230 KIRCHHEIM/TECK GERMANY Subject to modification! No liability for printing errors! 03/2018...
- Page 16 Please provide the dimensional differences if necessary. 8. Please note that the outer airfoil part, the typical "ear" or winglet for the AMIGO V, is folded into the drawing plane in the airfoil. Furthermore, the ribs (46 and 80) are shown vertically.
