Table 5 Advanced Menu – Super Io Configuration - Quanmax QDSP-400 Series User Manual

M a i n A d v a n c e d
Super IO Configuration
> Serial Port 1 Configuration
Table 6 Advanced Menu – Super IO Configuration - Serial Port 1 Configuration
M a i n A d v a n c e d
Serial Port 1 Configuration
Serial Port
Device Settings
Change Setting
Serial Port 1 Type
Serial Port
Options: Disabled, Enabled
Change Settings
Options: Auto;
IO=3F8h; IRQ=4;
IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
Serial Port 1 Type
Options: RS232, RS422, RS485

RS485 Duplex Mode
Options: Half Duplex, Full Duplex

RS485 Auto Flow Control
Options: Disabled, Enabled
QDSP-400 Series User's Manual
Table 5 Advanced Menu – Super IO Configuration
