- Page 1 QDSP-207B Digital Signage Player with Intel® Ivy Bridge Platform User’s Guide QDSP-207B User’s Manual...
-
Page 2: Table Of Contents
Mechanical Dimensions ................17 Chapter 2 Getting Started ....................18 Setting up your PC ..................18 Connecting VESA Mount on QDSP-207B ..........23 Mounting your PC to a monitor ..............24 Changing Memory and mini-PCIe...............25 Chapter 3 AMI BIOS Setup ....................28 Overview ......................28... -
Page 3: Figures & Tables
Figure 7 RJ45 connector ..................21 Figure 8 Turning on the system ................22 Figure 9 VESA Mount Assembly .................23 Figure 10 VESA Mount on QDSP-207B ............23 Figure 11 VESA mounting ..................24 Figure 12 Opening the Cover on the Bottom ............25 Figure 13 Bottom view of Main Board ..............25 Figure 14 SO-DIMM Installation (1)..............26... -
Page 4: Qdsp-207B User's Manual
Figures & Tables Table 17 Boot Menu ....................41 Table 18 Security Menu ..................42 Table 19 Save & Exit Menu..................43 QDSP-207B User’s Manual... -
Page 5: Safety Instructions
Turning off the system power switch does not remove power to components. When Working Inside a Computer Before taking covers off a computer, perform the following steps: Turn off the computer and any peripherals. QDSP-207B User’s Manual... -
Page 6: Preventing Electrostatic Discharge
ESD workstation or grounded. This will discharge any static electricity that may have built up in your body. When transporting a sensitive component, first place it in an antistatic container or packaging. QDSP-207B User’s Manual... -
Page 7: Instructions For Lithium Battery
Do not dispose of lithium batteries in domestic waste. Dispose of the battery according to the local regulations dealing with the disposal of these special materials (e.g. to the collecting points for disposal of batteries) QDSP-207B User’s Manual... -
Page 8: Preface
Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. QDSP-207B User’s Manual... -
Page 9: Maintaining Your Computer
Buildings in which climate is controlled usually maintain an acceptable level of humidity for system equipment. However, if a system is located in an unusually humid location, a dehumidifier can be used to maintain the humidity within an QDSP-207B User’s Manual... - Page 10 AC power is lost, the battery can provide power to the system for a limited amount of time, depending on the UPS system. UPS systems range in price from a few hundred dollars to several thousand QDSP-207B User’s Manual...
- Page 11 Surge protectors should be used with all UPS systems, and the UPS system should be Underwriters Laboratories (UL) safety approved. QDSP-207B User’s Manual...
-
Page 12: Chapter 1 Introduction
Chapter 1 Introduction Overview The QDSP-207B is a compact size Box PC ideal for space critical applications. This embedded hardware platform features 3rd Generation Intel® Core™ i5/i7 Processors, Intel® HM76 Express chipset, and DDR3 1066/1333/1600 SO-DIMM. It comes with a 2.5” SATA hard drive or SSD, HDMI, D VI, 2 x USB 2.0, 4 x USB 3.0, eSATA, COM, and HD Audio. -
Page 13: Product Specifications
Temperature / Operating: 0°C to 40°C, 0%-90%, non-condensing Humidity Storage: -20°C to 80°C, 0%-90%, non-condensing OS Support Window s Xp/XPe/Window s 7/Window s 8/ Linux Mounting VESA-mount Certifications CE, FCC Class A Table 1 QDSP-207B product specifications QDSP-207B User’s Manual... -
Page 14: System Tour
The WiFi LED will light when the WiFi is on. Storage LED (Red) The hard disk/card reader LED blinks when data is being written into or read from the HDD/Card Reader. The USB (Universal Serial Bus) port is compatible with USB devices such as QDSP-207B User’s Manual... - Page 15 The Line-in jack is designed to take input from a higher-powered sound source. CAUTION This connector do not support hot-swapping. Users should not connect or disconnect their eSATA/USB (combo) & CF devices from PC when the system is Working. QDSP-207B User’s Manual...
-
Page 16: Figure 2 Rear I/Os
The eight-pin RJ-45 LAN port supports a standard Ethernet cable for connection to a local network. DVI-I DVI-I connector for DVI-D or VGA output D-Sub 9 pin connector for RS-232 connection WiFi External Antenna Spared hole on the casing for connecting WiFi external antenna QDSP-207B User’s Manual... -
Page 17: Mechanical Dimensions
Chapter 1 Mechanical Dimensions 200 x 35 x 153.1 mm (W x H x D) Figure 3 Mechanical Dimensions QDSP-207B User’s Manual... -
Page 18: Chapter 2 Getting Started
Figure 4 Connect the DVI cable NOTE When the system reboots without connecting the DVI, there might be no image on screen when you insert the DVI cable. Please pressing <Ctrl>+<Alt>+<F4> simultaneously to show the image on screen. QDSP-207B User’s Manual... -
Page 19: Figure 5 Connect Usb Mouse & Keyboard
Chapter 2 Connecting USB mouse & keyboard Your QDSP-207B does not come with a keyboard and mouse, but you can use any USB keyboard or mouse with your computer. USB 2.0 eSATA/USB USB 3.0 Figure 5 Connect USB mouse & keyboard NOTE Using a third-party USB mouse or keyboard may require software drivers. -
Page 20: Figure 6 Com Port
Chapter 2 COM port COM port with the pin definitions. Half Duplex Full Duplex RS-232 RS-422 RS-485 RS-485 DATA- DATA+ RI / +5V* NA / +5V* NA / +5V* NA / +5V* Figure 6 COM port QDSP-207B User’s Manual... -
Page 21: Figure 7 Rj45 Connector
Connecting to a network device Connect one end of a network cable to the LAN port on the system rear panel and the other end to a hub or switch. RJ 45 Figure 7 RJ45 connector QDSP-207B User’s Manual... -
Page 22: Figure 8 Turning On The System
Connect the supplied AC power cord to the system AC power inlet. Connect the other end of the AC power cord to a corresponding outlet. Press the power switch to turn on the system DC Jack Power Button Figure 8 Turning on the system QDSP-207B User’s Manual... -
Page 23: Connecting Vesa Mount On Qdsp-207B
Chapter 2 Connecting VESA Mount on QDSP-207B Take out the VESA mounting kit form your package and facing it onto the bottom of QDSP-207B; then tightening the screws on your QDSP-207B as figures shown below. Figure 9 VESA Mount Assembly Following figures are the complete status when you done. -
Page 24: Mounting Your Pc To A Monitor
Firstly, mount your VESA kit on the backside of the monitor with four screws in the package. Secondly, place the QDSP-207B on the VESA mounting kit and then tightening the screws from the holes on both sides of the VESA bracket - make sure the computer is fitting well on the bracket. -
Page 25: Changing Memory And Mini-Pcie
Chapter 2 Changing Memory and mini-PCIe Firstly, Opening the cover by loosening the two screws on the bottom of QDSP-207B as shown below; Figure 12 Opening the Cover on the Bottom Then you may able to change the DDR SO-DIMM and/or mini-PCIe modules. -
Page 26: Figure 14 So-Dimm Installation (1)
SO-DIMM. Lift it out of the socket. Make sure you store the SO-DIMM in an anti-static b ag. The socket must b e populated with memory modules of the same size and manufacturer. QDSP-207B User’s Manual... -
Page 27: Figure 16 Mini-Pcie Installation
Chapter 2 Changing mini-PCIe (1) Pla ce your mini‐PCIe module towa rd the mini‐PCIe socket. Figure 16 Mini-PCIe Installation (2) Ti ghtening the s crew on the hole of the mini ‐PCIe module as shown above. QDSP-207B User’s Manual... -
Page 28: Chapter 3 Ami Bios Setup
It is possible for the CMOS battery to fail, which will cause data loss in the CMOS only. If this happens you will need to reconfigure your BIOS settings. QDSP-207B User’s Manual... -
Page 29: Main Menu
1333 MHz F1: General H elp Sys tem date [Wed 08/22/2012] F2: Previous Val ues Sys tem ti me [09:43:19] F3: Optimized Defaults F4 Save & Exit ESC Exit Version 2.15.1227. Copyright (C) 2010, American Megatrends, Inc. QDSP-207B User’s Manual... -
Page 30: Advanced Menu
Version 2.15.1227. Copyright (C) 2010, American Megatrends, Inc. Onboard LAN 1 Controller Options: Disabled, Enabled Onboard LAN 1 Boot Options: Disabled, Enabled Onboard LAN 2 Controller Options: Disabled, Enabled Onboard LAN 2 Boot Options: Disabled, Enabled Audio Controller Options: Disabled, Enabled QDSP-207B User’s Manual... -
Page 31: Table 4 Advanced Menu – Display Configuration
Options:32M, 64M, 96M, 128M, 160M, 192M, 224M, 256M, 288M, 320M, 352M, 384M, 416M, 448M, 480M, 512M, 1024M DVMT Total Gfx Mem Options: 128M, 256M, MAX IGFX – Boot Type Options: VBIOS Default, CRT, DVI, HD MI, DP QDSP-207B User’s Manual... -
Page 32: Table 5 Advanced Menu –Power Management Configuration
Options: Power Off, Power On, Last State Resume By PCIE Device Options: Disabled, Enabled Resume By RTC Alarm Options: Disabled, Enabled EUP Power Saving Mode Options: Disabled, Enabled Watchdog Timer Configuration [Disabled] WDT Function ■ Options: Disabled, Enabled QDSP-207B User’s Manual... -
Page 33: Table 6 Advanced Menu –Cpu Ad Vanced Configuration
Options: Disabled, Enabled Hyper Threading Options: Disabled, Enabled VT-d Options: Disabled, Enabled Active Processor Cores Options: All, 1, 2, 3 Limit CPUID Maximum Options: Disabled, Enabled Execute Disable Bit Options: Disabled, Enabled Intel ® Virtualization Tech Options: Disabled, Enabled QDSP-207B User’s Manual... -
Page 34: Table 7 Advanced Menu –Trusted Computing
Current Status Information F1: General H elp SUPPORT TURNED OFF F2: Previous Val ues F3: Optimized Defaults F4 Save & Exit ESC Exit Version 2.15.1227. Copyright (C) 2010, American Megatrends, Inc. Security De vice Support Options: Disabled, Enabled QDSP-207B User’s Manual... -
Page 35: Table 8 Advanced Menu –Sata Configuration
Options: IDE, AHCI SATA Controller Speed Options: Gen 1, Gen 2, Gen 3 Port Options: Disabled, Enabled SATA Device Type Options: Hard Disk Driver, Solid State Driver Hot Plug Options: Disabled, Enabled External SATA Options: Disabled, Enabled QDSP-207B User’s Manual... -
Page 36: Table 9 Advanced Menu – Intel Rapid Start Technology
+- Change Opt. Secure Mode Extensions (SMX) [Enabled] F1: General H elp Intel T XT (LT) Support [Disabled] F2: Previous Val ues F3: Optimized Defaults F4 Save & Exit ESC Exit Version 2.15.1227. Copyright (C) 2010, American Megatrends, Inc. QDSP-207B User’s Manual... -
Page 37: Table 11 Ad Vanced Menu –Amt Configuration
MEBx Selection Screen Options: Disabled, Enabled Hide Un-Configure ME Confirmation Options: Disabled, Enabled MEBx Debug Message Output Options: Disabled, Enabled Un-Configure ME Options: Disabled, Enabled AMT Wait Timer Options: 0 Disable ME Options: Disabled, Enabled Options: Disabled, Enabled QDSP-207B User’s Manual... -
Page 38: Table 12 Ad Vanced Menu –Usb Configuration
Options: Disabled, Enabled XHCI hand-off Options: Disabled, Enabled EHCI hand-off Options: Disabled, Enabled XHCI Pre-Boot Driver Options: Disabled, Enabled XHCI Mode Options: ,Auto, Smart Auto, Disabled, Enabled San Disk Options: Auto, Floppy, Forced FDD, Hard Disk, CD-ROM QDSP-207B User’s Manual... -
Page 39: Table 13 Ad Vanced Menu – Super Io Configuration
IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; Serial Port Type Options: RS232, RS422, RS485 QDSP-207B User’s Manual... -
Page 40: Table 15 Ad Vanced Menu –H/W Monitor
S e c u r i t y S a v e & E x i t A d v a n c e d ISCT Configuration [Disabled] Version 2.15.1227. Copyright (C) 2010, American Megatrends, Inc. ISCT Configuration Options: Disabled, Enabled QDSP-207B User’s Manual... -
Page 41: Boot Menu
Options: On, Off Boot Option #1 Options: San Disk, UEFI: San Disk, Disabled Boot Option #2 Options: San Disk, UEFI: San Disk, Disabled Hard Drive BBS Priorities ■ Boot Option #1 [San Disk ] Options: San Disk, Disabled QDSP-207B User’s Manual... -
Page 42: Security Menu
The pass word l ength mus t be in the followi ng range: F2: Previous Val ues Minimum Length F3: Optimized Defaults Maxi mum length F4 Save & Exit ESC Exit Admi nistrator Pass word User Pass word Version 2.15.1227. Copyright (C) 2010, American Megatrends, Inc. QDSP-207B User’s Manual... -
Page 43: Save & Exit Menu
Enter: Sel ect Save C hanges +- Change Opt. Discard Changes F1: General H elp Restore Defaults F2: Previous Val ues F3: Optimized Defaults F4 Save & Exit ESC Exit Version 2.15.1227. Copyright (C) 2010, American Megatrends, Inc. QDSP-207B User’s Manual... - Page 44 Load Optimal Default values for all the setup values. This option allows you to load failsafe default values for each of the parameters on the Setup menus, which will provide the most stable performance settings. The F8 key can be used for this operation. QDSP-207B User’s Manual...
-
Page 45: Chapter 4 Driver Installation
You can download the drivers for the QDSP-207B from our website and install as instructed there. For other operating systems, please contact us.
