Summary of Contents for Blizzard Lighting Shoqwave X6
- Page 1 Blizzard Lighting, LLC http://www.blizzardpro.com Waukesha, WI USA Copyright (c) 2019...
-
Page 2: Table Of Contents
Master/Slave Mode Settings Auto Mode Sound Active Mode DMX Channel Values In-Depth Troubleshooting 5. Appendix Keeping Your Shoqwave™ X6 As Good As New Returns (Gasp!) Shipping Issues Tech Specs Page 2 Shoqwave™ X6 Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 3: Shoqwave™ X6
Blizzard Lighting™ assumes no responsibility or liability for any errors or omissions that may appear in this user manual. Blizzard Lighting™ reserves the right to update the existing document or to create a new document to correct any errors or omissions at any time. -
Page 4: Safety Instructions (Don't Stick Your Hand In The Toaster!)
Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please open a support ticket at www. blizzardpro.com/support. Page 4 Shoqwave™ X6 Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 5: Meet The Shoqwave™ X6
R/G/B/W #1 Dimmer Channels 18-21 R/G/B/W #2 Dimmer Channels 22-25 R/G/B/W #3 Dimmer Channels 26-29 R/G/B/W #4 Dimmer Channels 30-33 R/G/B/W #5 Dimmer Channels 34-37 R/G/B/W #6 Dimmer Channels Reset Page 5 Shoqwave™ X6 Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 6: The Shoqwave™ X6 Pin-Up Picture
10W RGBW Heads 4-in-1 LEDs (x6) Built-in Cooling Microphone Vents 4-Button Control Panel with LED Menu Display Figure 2: The Rear Connections Power Input Input DMX Output Fuse Holder Page 6 Shoqwave™ X6 Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 7: Setup
Maximum capacitance between conductors – 30 pF/ft. Maximum capacitance between conductor & shield – 55 pF/ft. Maximum resistance of 20 ohms / 1000 ft. Nominal impedance 100 – 140 ohms Page 7 Shoqwave™ X6 Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 8: Cable Connectors
Step 3: Connect other fixtures in the chain from output to input as above. Place a DMX terminator on the output of the final fixture to ensure best communication. Page 8 Shoqwave™ X6 Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 9: Fixture Linking (Master/Slave Mode)
• Safety cables MUST ALWAYS be used. • Never mount in places where the fixture will be exposed to rain, high humidity, extreme temperature changes or restricted ventilation. Page 9 Shoqwave™ X6 Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 10: Operating Adjustments
Press the <ENTER> button to select the menu function currently dis- played, or to enable a menu option. To return to the previous option or menu without changing the value, press the <MENU> button. Page 10 Shoqwave™ X6 Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 11: Control Panel Menu Structure
3.) Press the <ENTER> to confirm, or <MENU> to exit. 4.) For mic sensitivity, navigate the main menu to Sens, and press <ENTER>. 5.) Highlight a level ranging from 0% to 100%, and press <ENTER>. Page 11 Shoqwave™ X6 Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 12: Dmx Channel Values In-Depth
108 <-> 107 227 <-> 236 Effect 23 108 <-> 117 108 <-> 117 237 <-> 246 Effect 24 118 <-> 127 118 <-> 127 247 <-> 255 Effect 25 Page 12 Shoqwave™ X6 Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 13: Troubleshooting
Make sure all connectors are seated properly and securely. Responding / Use Only DMX Cables and/or check cables for defects Responding Errati- Install a Terminator. cally Reset fixture(s). If problems persists, visit www.blizzardpro.com/support. Page 13 Shoqwave™ X6 Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 14: Appendix
Damage incurred in shipping is the responsibility of the shipper, and must be reported to the carrier immediately upon receipt of the items. Claims must be made within seven (7) days of receipt. Page 14 Shoqwave™ X6 Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 15: Tech Specs
Neutrik AG, Neutrik USA and their related entities, however they are not manufactured by, affiliated with or endorsed by Neutrik AG, Neutrik USA, or any related entity. Neutrik® and powerCON® are registered trademarks of Neutrik AG. Page 15 Shoqwave™ X6 Manual Rev. A © 2019 Blizzard Lighting, LLC... - Page 16 Enjoy your product! Our sincerest thanks for your purchase! --The team @ Blizzard Lighting...
